Agilent / Varian IDP3 Dry Scroll Vacuum Pump, IDP3B01, 1 PHASE, 115 VAC, 60 HZ
The Varian, Inc. IDP-3 Dry Scroll Pump is an innovative, compact, high-performance, oil-free vacuum pump that is suitable for a wide variety of applications. It is the smallest scroll pump made for general vacuum applications, which makes it easy to integrate it into OEM systems, and it weighs only 21 pounds (9.5 kg). Yet with a pumping speed of 60 liters/min. and a very low base pressure of 250 millitorr, it is the highest-performing dry pump in its class.
Features: - Oil-free, for no contamination of the vacuum system
- Hermetic design with fully isolated motor and bearings
- Small size: 14 × 7 × 6 inches (351 × 181 × 140 mm)
- Lower base pressure than diaphragm pumps
- No mechanisms subject to catastrophic failure
- Low noise and vibration
Technical Specs: | Peak pumping speed (60 Hz) | 60 L/m, 3.6 m³/hr, 2.1 cfm | | Peak pumping speed (50 Hz) | 50 L/m, 3.0 m³/hr, 1.8 cfm | | Ultimate pressure | 2.5 × 10-1 torr (3.3 × 10-1 mbar, 33 Pa) | | Maximum inlet pressure | 1 atm (0 psig) | | Maximum outlet pressure | 1.4 atm (6.5 psig) | | Exhaust connection | 1⁄4-in. female nat’l pipe thread
(10 mm hose barb provided) | | Exhaust connection adapter | NW16 KF adapter provided | | Gas ballast connection | 1⁄8-in. female nat’l pipe thread | | Ambient operating temp | 5 to 40 °C (41 to 104 °F) | | Storage temperature | –20 to 60 °C (–4 to 140 °F) | | Motor rating | 0.16 horsepower (0.12 kW) | | Motor thermal protection | Automatic | | Rotation speed | High-clarity color touch screen | | Cooling | Air-cooled | | Weight | 9.5 kg (21 lbs)
Ship: 10.5 kg (23 lbs) | | Restrictions | No corrosive, explosive,
particulate-forming gas | | Leak rate (exhaust sealed) | <1 × 10-6 std-cc/sec helium | | Noise level (ISO 11201) | 55 dB(A) | | Vibration at inlet (ISO 11201) | 1.5 mm/sec | | Compliance | CE, CSA, CSA/CUS,
Semi S2-703, RoHS |
PN06760
