Pfeiffer VacuumHi HiCube 80 Pro / Penta 35 Turbomolecular Pump Station, DN 63 ISO-K, 230V AC, 50/60 Hz, PMS4151000 The HiCube Pro pumping stations are suitable for all high vacuum applications and are available with dry and oil-sealed backing pumps having pumping speeds of up to 685 l/s. The HiCube Pro is especially characterized by its extremely fast pump-down times. Available for selection as backing pumps are the dry pumps from the XtraDry line with pumping speeds of up to 7.5 m3 / h or rotary vane pumps with pumping speeds of up to 34 m3 / h. - Combination pumping station incorporating turbopump and backing pump for all high vacuum applications
- Air-cooled and ready for operation with HiPace 80 and Penta 35 rotary vane backing pump
- DN 63 ISO-K
- 230 V AC, 50/60 Hz
Technical Data : | Cooling method, standard | Air | | Flange (in) | DN 63 ISO-K | | Flange (out) | G 1 / 2" | | Mains requirement | 230 V AC, 50/60 Hz | | Pump-down time for vacuum chamber sizes of 1000 l | 990 s | | Pump-down time for vacuum chamber sizes of 100 l | 99 s | | Pump-down time for vacuum chamber sizes of 10 l | 10 s | | Pumping speed backing pump | 35 m3 / h | | Pumping speed turbopump | 67 l/s | | Roughing pump | PentaLine 35 | | Ultimate pressure | 1 · 10-7 mbar | | Weight | 84.2 kg | The HiCube Classic pumping stations are suitable for all high and ultra high vacuum applications and are available with dry and oil-sealed backing pumps having pumping speeds of up to 685 l/s. Available for selection as backing pumps are dry diaphragm pumps with pumping speeds of up to 4.3 m3 / h or rotary vane pumps with pumping speeds of up to 6 m3 / h.
PN06296
