This is a original OEM Agilent Technologies DS102, DS202, DS302 Minor Maintenance Service Kit, 9499370
A&J Vacuum also repair / rebuild and service all Alcatel Adixen Turbo Pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page.
THERE ARE NO RETURNS ON THIS PRODUCT.
Overview:
The Varian SD 700 Minor Repair / Rebuild Kit, for SD700 Vacuum Pump, 54285 Vacuum Pump Minor Repair Kit includes everything needed for minor overhauls on the Varian SD700 Rotary Vane Vacuum Pump. P1879301
Varian SD700 Minor Repair Kit / Rebuild Kit contains the following parts:
|
PN 54285 KIT,MINOR,1033/2033 |
||
|
PN |
Desc. |
Qty |
|
103306 |
GASKET,SIGHT GLASS |
1 |
|
105452R |
SIGHT GLASS,OIL,PLASTIC |
1 |
|
320067 |
O'RING,VITON,63.09 X 3.53 MM |
1 |
|
53443 |
VALVE,DISCHRG,VITON 2033/63C |
3 |
|
54091 |
COUPLER,ELSTC,BLUE,2030-2033C |
1 |
|
54114 |
SPRING,GAS BALLAST |
1 |
|
54128 |
GASKET,CASE,2033C |
1 |
|
54134 |
VALVE,EXHAUST,2033/63C |
1 |
|
54145 |
SPRING |
1 |
|
54149 |
SPRING |
1 |
|
54196 |
MEMBRANE,OIL PUMP |
1 |
|
54224 |
CLAPPER,2033/63 |
1 |
|
73446 |
WASHER,WAVED,S.S.,M10 |
4 |
|
73460 |
WASHER,WAVED,S.S.,M6 |
16 |
|
73461 |
WASHER,WAVED,S.S.,M8 |
23 |
|
79234 |
O'RING,BUNA,8 X 2 MM |
2 |
|
82108 |
O'RING,BUNA,9.19 X 2.62 MM |
1 |
|
82109 |
O'RING,BUNA,10.77 X 2.62 MM |
1 |
|
82112 |
O'RING,BUNA,15.54 X 2.62 MM |
1 |
|
65059 |
PAD,FELT,2033-2033CP+ |
1 |
|
65079 |
ASSY,SIGHT GLASS,2033/2063CP+ |
1 |
|
71188 |
C-CLIP,2033/63C |
2 |
|
71338 |
NUT |
1 |
|
75024 |
SCREW,SOCKET HEAD CAP,YLW CH |
1 |
|
76135 |
Sight glass, Window,W/seal |
1 |
|
76261 |
PIN,COTTER,2033/63 |
1 |
|
76261C |
C-CLIP,2033/63 |
1 |
|
79010 |
O'RING,BUNA,128 X 2 MM |
4 |
|
79051 |
O'RING,BUNA,41 X 3 MM |
1 |
|
79100 |
SEAL,SHAFT,BUNA |
3 |
|
79101 |
SEAL,SHAFT,VITON |
1 |
|
82024 |
O'RING,VITON,12.37 X 2.62 MM |
4 |
|
82122 |
O'RING,BUNA,29.3 X 3.6 MM |
1 |
|
82129 |
O'RING,BUNA,40.64 X 5.33 MM |
1 |
|
82604 |
PLUG,DRAIN,PLASTIC,2004A-2063C |
1 |
|
82925 |
PLUG,FILL,2033-2063C |
1 |
|
83633 |
O'RING,BUNA,38 X 2.5 MM |
1 |
|
84149 |
O'RING,BUNA,16 X 2 MM |
1 |
|
87926 |
O'RING,BUNA,44 X 3 MM |
1 |
|
87954 |
SPRING,VALVE |
3 |
|
54451G |
VANE,GX,OIL PUMP |
1 |
|
DRAWING |
Drawing Layout |
1 |
A&J Vacuum also repair / rebuild and service all Alcatel Vacuum and Turbo Pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page.
THERE ARE NO RETURNS ON THIS PRODUCT.
Varian DS102 DS202 DS302 OEM Minor Maintenance Agilent DS 102 DS 202 DS 302 kit, 985700212001, replacement for Agilent P/N 9499370
Engineered to meet or exceed OEM specifications, our kits and spares re designed part for part, providing you the same quality components you would find in OEM kits, but at fraction of the cost.
A&J Vacuum also repair / rebuild and service all Alcatel Adixen Turbo Pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page.
THERE ARE NO RETURNS ON THIS PRODUCT.
Varian DS402 DS602 Minor Maintenance Service kit, 985700228008, Agilent, replacement for Agilent P/N 9499371
Engineered to meet or exceed OEM specifications, our kits and spares re designed part for part, providing you the same quality components you would find in OEM kits, but at fraction of the cost.
The DS-402 / DS-602 Minor Repair Kit contains the following parts:
| DESCRIPTION | PART NO. | QTY |
|
O-Ring |
A320109 |
1 |
|
O-Ring |
E02122009V |
1 |
|
O-Ring |
E02122058 |
1 |
|
Casing Gasket Cork |
G300052 |
1 |
|
Viton Shaft Seal |
G310056 |
1 |
|
O-Ring |
G320108 |
1 |
|
O-Ring |
G320126 |
2 |
|
O-Ring |
G320130 |
1 |
|
O-Ring |
G320131 |
1 |
|
O-Ring |
G320132 |
2 |
|
Viton Exhaust Valve |
G380016 |
3 |
|
Buna Valve |
G380017 |
1 |
|
Compression Spring |
G490028 |
1 |
|
Coupling Element |
G500501 |
1 |
|
ASB Shutter Viton |
G580039 |
1 |
|
ASB Shutter Valve |
G580040 |
1 |
|
Spring |
G619561A |
3 |
|
Buffer Foot |
G640015 |
2 |
|
O-Ring |
L23970106 |
1 |
|
O-Ring |
L23970191 |
1 |
|
O-Ring |
L72591000 |
1 |
|
O-Ring |
L72591002 |
2 |
A&J Vacuum also repairs and services all Alcatel Adixen Turbo Pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page.
THERE ARE NO RETURNS ON THIS PRODUCT.
Overview:
Major Repair / Rebuild Kit for Agilent / Varian DS 202 and DS 302 Rotary Vane Vacuum Pumps 9499381
A&J Vacuum also repair / rebuild and service all Alcatel Adixen Turbo Pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page.
THERE ARE NO RETURNS ON THIS PRODUCT.
Varian SD 300 Rotary Vane Vacuum Pump Major Repair / Rebuild Kit, 52611FR
Overview:
Varian SD300, SD 300 Major Repair/Rebuild Kit includes everything needed for major overhauls on the Varian SD300 Rotary Vane Vacuum Pump.
A&J Vacuum also repair / rebuild and service all Varian Vacuum and Turbo Pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page.
Overview:
Varian SD90, Varian SD200, Varian SD300 and Varian SD450 Vacuum Pump Minor Repair / Rebuild Kit, includes everything needed for minor overhauls on Varian Rotary Vane Vacuum Pumps.
We also do minor and major repairs for all Alcatel Rotary Vane Vacuum Pumps.
Minor Maintenance Repair Kit, 52610 contains the following parts:
| DESCRIPTION | PART NO. | QTY |
| Valve Spring | 52541 | 4 |
| Coupling | 52553 | 1 |
| Fan Plate Gasket | 52555 | 1 |
| Exhaust Clapper | 52557 | 1 |
| Discharge Valve | 52655 | 4 |
| Case Gasket | 52755 | 1 |
| Felt Pad | 52990 | 1 |
| Washer | 73339 | 3 |
| O-Ring, 28 x 5 mm | 79238 | 1 |
| O-Ring, 82 x 2 mm | 82033 | 5 |
| Shaft Seal | 82063 | 4 |
| O-Ring, 26.57 x 3.53 mm | 82120 | 1 |
| O-Ring, 29.3 x 3.6 mm | 82122 | 1 |
| O-Ring, 38 x 2.5 mm | 83633 | 1 |
| C-Clip | 83653 | 2 |
| Gas Ballast Valve | 52562B | 1 |
| Gas Ballast Spring | 52563 | 1 |
| Gas Ballast Spring Ball | 52564 | 1 |
| Exhaust Clapper | 52642 | 1 |
| Retaining Pin | 54071 | 1 |
| Doweal Pin | 71050 | 1 |
| C-Clip | 71161 | 1 |
| Waved Washer | 73460 | 9 |
| Waved Washer | 73461 | 6 |
| O-Ring, 5 x 2 mm | 82105 | 1 |
| Gas Ballast Ball | 82522 | 1 |
| O-Ring, 16 x 2 mm | 84149 | 2 |
| White Front Locking Carton | U30007193 | 1 |
| Nib | 54340V | 1 |
A&J Vacuum also repair / rebuild and service all Varian Vacuum and Turbo Pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page.
THERE ARE NO RETURNS ON THIS PRODUCT.
Varian DS 42 / Agilent DS42 Minor Maintenance Service Seal kit, 985700212042, Agilent DS-42
Engineered to meet or exceed OEM specifications, our kits and spares re designed part for part, providing you the same quality components you would find in OEM kits, but at fraction of the cost.
A&J Vacuum also repair / rebuild and service allVarian DS 42 / Agilent DS42 Vacuum Pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page.
Varian SD90 Major Repair / Rebuild Kit, 52614FR, for SD 90 Varian SD90 Vacuum Pump
Overview:
Varian SD90 Major Repair / Rebuild Kit, 52614FR includes everything needed for major overhauls on the Varian SD90 Rotary Vane Pump.
A&J Vacuum also repair / rebuild and service all Varian Vacuum and Turbo Pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page.
Varian SD90 Major Repair / Rebuild Kit contains the following parts:
| DESCRIPTION | PART NO. | QTY |
| ASB Lever | 52750 | 1 |
| Valve Spring | A52541 | 2 |
| Coupling | A52553 | 1 |
| Fan Plate Gasket | A52555 | 1 |
| Exhaust Clapper | A52557 | 1 |
| Gas Ballast Valve - Viton | A52562 | 1 |
| Gas Ballast Valve - Buna | A52562B | 1 |
| Gas Ballast Spring | A52563 | 1 |
| Ball Spring | A52564 | 1 |
| Exhaust Clapper | A52642 | 1 |
| Exhaust Valve | A52655 | 2 |
| Oil Case Gasket | A52755 | 1 |
| Felt Pad | A52990 | 1 |
| Vane Spring | A53040 | 4 |
| Pin | A71050 | 1 |
| Clip | A71161 | 1 |
| Nut | A71211 | 4 |
| Nut | A71214 | 3 |
| Flat Washer M4 | A73339 | 3 |
| Waved Washer M6 | A73454 | 9 |
| Waved Washer M8 | A73455 | 6 |
| Stage O-Ring | A79030 | 5 |
| O-Ring | A79238 | 1 |
| O-Ring | A82056 | 1 |
| Viton Shaft Seal | A82063 | 3 |
| Double Lip Viton Shaft Seal | A82063-01 | 1 |
| O-Ring | A82105 | 1 |
| O-Ring | A82120 | 1 |
| O-Ring | A82122 | 1 |
| Steel Ball | A82522 | 1 |
| Drain Plug | A82604 | 2 |
| Sight Glass | A83546 | 1 |
| Clip | A83653 | 2 |
| 2nd Stage Vane | A83946G | 4 |
| O-Ring | A84149 | 2 |
THERE ARE NO RETURNS ON THIS PRODUCT.
Varian DS 42 Coupling Element (Spider) 360071, DS-42 (Varian only) NOT for Agilent DS42
Engineered to meet or exceed OEM specifications, our kits and spares re designed part for part, providing you the same quality components you would find in OEM kits, but at fraction of the cost.
A&J Vacuum also repair / rebuild and service all Varian DS42 / Agilent DS 42 Vacuum Pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page.
