- Corrosive Duty
- 550 / 660 W
- < 4 · 10-3 hPa
- Dual-Stage High Performance Rotary Vane Pump
Shopping Cart ( )
Pfeiffer DuoVane 12 C Rotary Vane Pump, 3-phase, 1/8", 2000280719 / PK D922 A23 14 / PKD922A2314
Condition:
New
Item#:PN58127
Mfr Part#:2000280719 / PK D922 A23 14 / PKD922A2314
Manufacturer:Pfeiffer Vacuum
Price upon request
CONTACT US
Features:
Pfeiffer DuoVane 12 C Rotary Vane Pump, 3-phase, 1/8", 2000280719 / PK D922 A23 14 / PKD922A2314
Pfeiffer DuoVane 12 C Rotary Vane Pump Features:
- Reliable
- Simple to use
- Powerful
- High performance
- Includes gas ballast valve
- Corrosive gas version, 3-phase motor
DuoVane 12 C Rotary Vane Pump / PK D922 A23 14 Overview:
Pfeiffer DuoVane 12 C series rotary vane pumps are two-stage, oil-sealed rotary displacement pumps for use in a low and medium vacuum. The rotary vane pump is available in the standard version with claw coupling and asynchronous motor.
Pfeiffer DuoVane 12C Line is the latest and the newest design within rotary vane pumps, with outstanding pumping performance.
The Pfeiffer DuoVane12 C rotary vane pump is an oil-sealed rotary displacement pump. The pumping system comprises the housing, the eccentrically mounted rotor, and the centrifugal and spring-loaded radially sliding vanes, which divide the suction chamber into multiple chambers.
The volume of each stator chamber changes periodically as the rotor rotates. This causes the gas to be drawn in at the vacuum flange, and compressed in the suction chamber by the rotation of the rotor until the exhaust valve opens against the atmospheric pressure at the outlet and expels the gas. The exhaust valve is oil-sealed. When the valve opens, a small quantity of oil penetrates into the suction chamber. In addition to lubrication, this also causes the gaps between the rotor, stator, and vanes to seal.
DuoVane12C RotaryVanePump Applications:
- Laboratories
- Technical gases
- CVD coating
- Pharma freeze drying
- Pumping of oxygen
A&J Vacuum services and repairs Pfeiffer DuoVane 12 C and 22 C, along with all other Pfeiffer Vacuum and Turbo Pumps available on our website. Please contact us for additional information concerning our service program or click http://www.ajvs.com/service.php to access our Services page. We likewise offer emergency service and repair upon request. For more information, please contact A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
Pfeiffer DuoVane 12 C Rotary Vane Pump, 3-phase, 1/8", 2000280719 / PK D922 A23 14 / PKD922A2314
Pfeiffer DuoVane 12 C Rotary Vane Pump Technical Data:
| Connection flange (in) | DN 25 ISO-KF |
| Connection flange (out) | DN 25 ISO-KF |
| Pumping speed at 50 Hz | 9.5 m³/h |
| Pumping speed at 60 Hz | 11.8 m³/h |
| Gas ballast | Yes |
| Ultimate pressure with gas ballast | 1 · 10-2 hPa |
| Ultimate pressure | 3 · 10-3 hPa |
| Continuous inlet pressure, max. | 50 hPa |
| Leakage rate safety valve | 1 · 10-5 Pa m³/s |
| Exhaust pressure, min. | Atmospheric pressure |
| Exhaust pressure, max | 1500 hPa |
| Rotation speed at 50 Hz | 1500 rpm |
| Rotation speed at 60 Hz | 1800 rpm |
| Ambient temperature | 12 – 40 °C |
| Temperature: Shipping | -25 – 55 °C |
| Continuous gas input temperature, max. | 40 °C |
| Operating altitude, max. | 2000 m |
| Motor type | 3-phase motor |
| Motor protection | Bimetal |
| Protection degree | IP43 |
| Rated power 50 Hz | 0.55 kW |
| Rated power 60 Hz | 0.66 kW |
| Input voltage(s) | 200 – 220 / 240 / 380 – 415 V AC, 50 Hz | 200 – 220 / 280 / 380 – 480 V AC (±5 %), 60 Hz |
| Operating fluid | F4 |
| Operating fluid amount | 1.2 l |
| Cooling method | Air (Forced convection) |
| Weight | 27 kg / 60 lb |
