Agilent Technologies VS MD30 Mobile Helium Leak Detector with TriScroll 620 Dry Scroll Pump, 120V, VSMD301
Agilent Technologies VS MD30 Mobile Helium Leak Detector with TriScroll 620 Dry Scroll Pump, 120V, VSMD301 Agilent Technologies VS MD30 Mobile Helium Leak Detector with TriScroll 620 Dry Scroll Pump, 120V, VSMD301 Agilent Technologies VS MD30 Mobile Helium Leak Detector with TriScroll 620 Dry Scroll Pump, 120V, VSMD301 Agilent Technologies VS MD30 Mobile Helium Leak Detector with TriScroll 620 Dry Scroll Pump, 120V, VSMD301
Agilent Technologies / Varian
Agilent Technologies VS MD30 Mobile Helium Leak Detector with TriScroll 620 Dry Scroll Pump, 120V, VSMD301, N
Need a repair?
Usually Ships within 1-3 Weeks
$30,841.58
Quantity:
Item#: PN00130 Mfr Part#: VSMD301

New Agilent Technologies VS MD30 Mobile Helium Mass Spectrometer Leak Detector with TriScroll 620 Dry Scroll Vacuum Pump, 120V, VSMD301, N

90-Day Warranty

This item comes with a full 90 day manufacturer warranty.

Financing Available

This item qualifies for our equipment financing program.

'Like us'

Receive free coupons on your next repair or purchase.

Overview

New Agilent Technologies VS MD30 Mobile Helium Leak Detector with TriScroll 620 Dry Scroll Pump, 120V, VSMD301

Agilent Technologies VS Series leak detectors combine the simplicity of two-button operation with advanced system intelligence. Start and vent button permit simple day-to-day operation. User friendly software offers intuitive navigation to vast system capabilities. Programmable test sequences simplify daily operation, minimize operator error, and maximize production efficiency. The TFT style touch screen features high definition and brightness with wide viewing angles. Setup for worldwide use, these leak detectors can be operated in multiple languages – English, French, German, Spanish, Korean, Japanese and Chinese – and units of measure. And the VS Series conforms to CE, UL and CSA standards, assuring global acceptance.

VS Series leak detectors employ Agilent’s primary pumps – rotary vane or scroll – and high vacuum pumps that deliver high inlet pumping speed and inlet pressure tolerance minimizing test cycle time and maximizing production throughput. State-of-the-art spectrometer and vacuum system design enable a broad range of test methods for specific applications. The high efficiency ion source and beam optics optimize sensitivity and mass separation, giving the VS Series very high sensitivity to meet the most stringent leak test requirements. At the same time, these leak detectors enjoy high test port pressure tolerance which permits detection of large leaks.

In addition, high helium pumping speed ensures fast system response and clean-up times. Primary pump and system mounting options may be selected to best suit application requirements and test environments, and the compact, lightweight design enables easy transport from one application to another. Robust design innovations allow the VS Series to conform to the most rigorous industrial standards and operate dependently in the most challenging environments.

PN00130

THIS ITEM COMES WITH A FULL 90 DAY MANUFACTURER WARRANTY.

Specifications

Primary Pump: TriScroll 620

Nominal Pumping Speed: 500 l/min

Sensitivity Ranges: 5 x 10-12 atm cc/sec

Minimum Detectable Leak: 5 x 10-12 mbar l/s

Maximum Test Port Pressure: 13 mbar

Calibration: Automated or Manual (Internal or External)

Communication Interface: RS232 and analog (standard), Discrete IO (optional)

Weight: 114 kg / 250 lbs

AJVS Brochures

Action Filename
Download Download AJVS_Vacuum_Pump_Turbo_Pump_Service_and_Repair.pdf
Download Download AJVS_Agilent_VS_MD30_Sales_and_Repair.pdf

Video

Agilent Varian VS Series Leak Detector

Service & Repair

AJVS Repair and Service of High Vacuum Equipment

A & J Vacuum Services provides repair service for all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair, Mass Spectrometer repair, Rotary Vane Pump repair, Vacuum Booster repair, and Leak detector repair. Our highly trained technicians have years of experience and guarantee the highest quality service.

We operate at our own full service repair facility in Clifton, NJ. We have invested in state-of-the-art equipment including; complete line of decontamination, cleaning, drying, balancing, vibration analysis and software to minimize failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.

We support all major manufacturers including Pfeiffer Vacuum, Alcatel / Adixen, Edwards Vacuum, Varian, Oerlikon / Leybod Vacuum, Vacuubrand, and Agilent Technologies.

Repair Steps

  1. Full incoming inspection and run up time check, vibration check, drive inspection.
  2. Full disassembly, decontamination and cleaning.
  3. Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
  4. Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and long pump life.
  5. Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10-9 Mbar l/s. Vibrations are analyzed and test data is digitally recorded.

Every pump and instrument is extensively tested for 48 hours. During our final tests, we monitor total pressure, temperature, vibration and noise level utilizing newest testing technologies and techniques specified by OEM. Upon request, we can provide our customers with a pump down graph. Call us for your free repair estimate at 1-973-249-0854.
