Pfeiffer Vacuum HiCube 400 Classic / DUO 5 M Turbomolecular Pump Station, DN 100 CF-F, 110V AC, 50/60 Hz, Castors, PMS2634100 / PMS2634000

The HiCube Classic pumping stations are suitable for all high and ultra high vacuum applications and are available with dry and oil-sealed backing pumps having pumping speeds of up to 685 l/s. Available for selection as backing pumps are dry diaphragm pumps with pumping speeds of up to 4.3 m³ / h or rotary vane pumps with pumping speeds of up to 6 m³ / h.

• Combination pumping station incorporating turbopump and backing pump for all high vacuum applications
• Air-cooled and ready for operation with HiPace 400 and DUO 5 M rotary vane backing pump
• DN 100 CF-F
• 110 V AC, 50/60 Hz

Technical data:

With the modular design principle of the new HiCube series, the never-before-seen versatility will satisfy the widest range of requirements in the pumping speed range from 35 l/s to 685 l/s. Fully configured and ready for immediate employment, the turbopump and backing pump offer a perfect interplay: “Plug and Play” the way you want it.

The HiCube mobile turbopumping station sets new standards: It offers a convincing combination that consists of a new turbopump from the HiPace series and a backing pump designed for the user’s specific application needs. Pfeiffer Vacuum offers you the new HiCube in Pro and Classic versions; available with dry or oil-sealed backing pump and an ultimate pressure of up to 5 • 10^-10 mbar. Available as a version within the HiCube series that offers especially compact dimensions is the HiCube Eco with pumping speeds of 35 l/s to 67 l/s.
