Edwards nXL110i HV Dry Pump, NW50, 200-230V 50/60 Hz, A77012420

Edwards nXL110i HV Dry Pump, NW50, 200-230V 50/60 Hz, A77012420

Edwards nXL110i HV Features:

• Single phase, air cooled and quiet
• 110 m3h-1 and 200 m3h-1 models optimised for LCMS and ICPMS inlet duty
• nXLi can also be used on chambers up to 100 litres, at continuous inlet pressures up to 15 mbar with occasional pump down
• Flexibility of control – manual, remote contact closure and RS485 serial communication
• An enhanced EMC variant for high-voltage operation 200 - 230 V (+/-10%) 50/60 Hz meeting the European harmonic emission requirements of EN61000-3-2
• Based on field proven iXL range for peace of mind
• Compact footprint
• Maintenance free for extended operation
• Built-in exhaust valve for anti-suck-back protection

nXL110i HV / A77012420 Overview:

Edwards is delighted tointroduce the new air cooled nXLi dry pump range, designed to deliver aconsistent performance worldwide with complete user flexibility in mind. Thisnew single phase pump is available in two options: nXL110i and nXL200i. Bothare optimised for LCMS and ICPMS duties and are capable of handling gas loadsof up to 25 slm. nXLi can also be used on chambers up to 100 litres, atcontinuous inlet pressures up to 15 mbar with occasional pump down.

Performance is at the core of nXLi.  The intelligent drive enables the system to achieve an enhanced performance plateau from single phase power supply and a consistent worldwide operation. The choice of control options are either manual, simple remote or serial communications.  These may be utilised to provide real control for the system builder.

nXLi provides a small footprint with quiet operation making it a convenient and flexible high performing, yet compact, vacuum pump.  The oil-free non-contacting pump mechanism will provide extended operation with maximum up time, up to five year service life, with zero maintenance and no oil to dispose of.

During the initial chamber pump down the nXLi is able to work harder than normal.  The intelligent transient overload protection will allow a higher power draw for a short period of time for initial evacuation of the chamber from atmospheric pressure to operating pressure.  This higher initial power boost enables the pump to overcome initial gas loads and once operating pressure is achieved less power is required.

nXLi is the latest addition to the Edwards intelligent pumping range and is the ideal dry pump for Scientific OEMs, LCMS end users, ICPMS end users and in applications where a consistent performance, control and reliability are essential.
