HiCube 300 Eco Pfeiffer Turbo Pumping Station, Includes HiPace 300 Turbo Pump ISO 100, MVP 015-2 DC Diaphragm Vacuum Pump and DCU 002 Control Unit, 100-240 V 50/60 Hz PMS7610000
Item#: PN20404 Mfr Part#: PMS7610000 Manufacturer: Pfeiffer Vacuum
Condition: New
New Pfeiffer HiCube300 Eco Turbo Pumping Station, Includes HiPace 300 Turbo Pump ISO 100, MVP 015-2 DC Diaphragm Vacuum Pump and DCU 002 Control Unit, PMS7610000, 100-240 VAC 50/60 Hz

Features:
  • Inlet flange: DN 100 ISO-K
  • Pumping speed : 260 l/s
  • Ultimate pressure: < 1 x 10-7mbar
  • Backing Pump Pumping Speed 1 m3/h

PRICE: $15,645.00
WEB SAVINGS: $845.00
YOU PAY: $14,800.00
Item#: PN20404 Mfr Part#: PMS7610000
HiCube 300 Eco Pfeiffer Turbo Pumping Station, Includes HiPace 300 Turbo Pump ISO 100, MVP 015-2 DC Diaphragm Vacuum Pump and DCU 002 Control Unit, 100-240 V 50/60 Hz PMS7610000
Item#: PN20404 Mfr Part#: PMS7610000 Manufacturer: Pfeiffer Vacuum

New HiCube 300 Eco Pfeiffer Turbo Pumping Station, Includes HiPace 300 Turbo Pump ISO 100, MVP 015-2 DC Diaphragm Vacuum Pump and DCU 002 Control Unit, PMS7610000, 100-240 VAC 50/60 Hz



Pfeiffer HiCube 300 Eco Overview


The Pfeiffer Vacuum HiCube300 Eco Turbo Pumping Station is the trully portable and bench top pumping unit for many of the High Vacuum Applications. Also available with CF-F Inlet Flangethat  makes this system trully Ultra High Vacuum (UHV).

The Hicube 300 Station has a modern design with the latest turbo pump and electronics technology.

What’s so special about the HiCube vacuum solution: The combination of a turbopump from the HiPace series and a backing pump designed for the user’s specific application needs. We offer you the HiCube in Pro and Classic versions; available with dry compressing or oil-sealed backing pump and an ultimate pressure of up to 5 · 10-10 hPa.

The HiCube Eco turbo pumping station is distinguished by its modular construction. Thanks to the many possibilities of combining different turbopumps and backing pumps, the HiCube Eco can be configured to meet the requirements of all applications in high and ultra-high vacuums. In addition, all HiCube Eco pumping stations feature connectivity for digital pressure sensors.

All HiCube Eco turbo pumping stations are fitted with particularly energy-efficient backing pumps that have a DC drive. The turbopump and the backing pump form a single unit in the pumping station. If there is no gas load in the
vacuum, the pumping station automatically reduces the backing pump output. This results in maximum energy savings.



Hicube 300 Eco Station Features:


  • Compact series of pumping stations for all high vacuum applications
  • Available in many configurations to meet every application Click Here for more Info.
  • Ultimate Pressure: < 1 x 10-7 mbar
  • Pumping Speed for N2: 260 l/s
  • Pumping speed backing pump at 50 Hz 1 m3/h
  • Air-cooled and ready for operation with HiPace 80 Turbo Pump and MVP 015 Dry Diaphragm Backing Pump
  • Pfeiffer HiCube 300 Eco comes with  ISO100-K inlet flange
  • DCU 002 Control Unit
  • HICUBE 300 Eco voltage requirement 100-240 V AC, 50/60 Hz;
  • Pumping Station Components: HiPace 300, MVP 015-2 DC, Cooling Fan, DCU 002
  • Weight 15.9 Kg / 35.05 lbs



Pfeiffer HiPace 300 Eco Product Description:


Pfeiffer HiCube 300 Eco Turbo Pumping Station PMS7610000, Product Overview



Typical High Vacuum Hicube300 Eco Applications:


  • Analytical
  • Leak Detection
  • Vacuum process technology
  • Research, Development and Scientific
  • Particle accelerators
  • Electron-beam welding
  • Solar Energy



Pfeiffer HiPace 300 Eco Dimensions:


Pfeiffer HiCube 300 Eco Turbo Pumping Station Dimensions ISO 100


Click Here for Pfeiffer HiCube 300 Manual

Click Here for Pfeiffer HiPace 300 Manual

Click Here for Pfeiffer MVP 015-2 DC Manual


A&J Vacuum also repair / rebuild and service all Pfeiffer HICUBE 300 ECO Pumping Stations PM S76 100 00, Pfeiffer Turbo Pumps along with all other Pfeiffer Vacuum Rotary Vane Pumps, Pfeiffer Dry Pumps, Pfeiffer Leak Detector Repair and all other Pfeiffer Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854

This item is non-returnable/non-refundable

New Pfeiffer HiCube 300 Eco Turbo Pumping Station, Includes HiPace 300 Turbo Pump ISO 100, MVP 015-2 DC Diaphragm Vacuum Pump and DCU 002 Control Unit, PMS7610000, 100-240 VAC 50/60 Hz



Pfeiffer Hicube 300 Technical Data:


Backing pump MVP 015-2
Cooling method, standard Air
Flange (in) DN 100 ISO-K
Flange (out) Silencer, G 1/8"
Mains connection: Voltage 100 – 240 V
Mains requirement 110 – 240 V AC, 50/60 Hz
Mains requirement: frequency (range) 50/60 Hz
Mains requirement: power consumption 270 W
Power consumption max. 270 W
Pumping speed backing pump at 50 Hz 1 m³/h | 0.59 cfm | 16.67 l/min
Pumping speed for N2 260 l/s
Sound pressure level ≤50 dB(A)
Turbopump HiPace 300
Type Turbo pumping station
Ultimate pressure < 1 · 10-7 hPa | < 7.5 · 10-8 Torr | < 1 · 10-7 mbar
Ultimate pressure without gas ballast < 1 · 10-7 hPa | < 7.5 · 10-8 Torr | < 1 · 10-7 mbar
Weight 15.9 kg | 35.05 lb



Pfeiffer MVP 015-2 DC Technical Data:


Pumping speed 1 m³/h | 0.59 cfm | 16.67 l/min
Ultimate pressure with gas ballast ≤ 6 hPa | ≤ 4.5 Torr | ≤ 6 mbar
Ultimate pressure without gas ballast ≤ 3.5 hPa | ≤ 2.62 Torr | ≤ 3.5 mbar
Flange (in) G 1/8"
Number of pumping stages 2
Flange (out) G 1/8" with silencer
Motor version DC motor
Voltage: Range ± 10 %
Current max. 4,6 A
Rated current absorption 2.9 A
Short circuit current of power supply, max. 45 A
Protection category IP20
Operating altitude, max. 2000 m
Rotation speed 540-2,600 rpm | 540-2,600 min-1
Cooling method, standard Convection cooled
Ambient temperature 5-40 °C | 41-104 °F | 278-313 K
Temperature: Storage 5-40 °C | 41-104 °F | 278-313 K
Intake pressure max. 1,100 hPa | 825 Torr | 1,100 mbar
Exhaust pressure, max. 1,100 hPa | 825 Torr | 1,100 mbar
I/O interfaces RS-485
Sound pressure level 50 dB(A)
Switch No
Mains cable No
Gas ballast Yes
Leak rate ≤ 5 · 10-4 Pa m3/s | ≤ 3.75 · 10-3 Torr l/s | ≤ 5 · 10-3 mbar l/s
Weight 2.7 kg | 5.95 lb

Click Here for Pfeiffer HiCube 300 Manual

Click Here for Pfeiffer HiPace 300 Manual

Click Here for Pfeiffer MVP 015-2 DC Manual


A&J Vacuum also repair / rebuild and service all Pfeiffer HICUBE 300 ECO Pumping Stations PM S76 100 00, Pfeiffer Turbo Pumps along with all other Pfeiffer Vacuum Rotary Vane Pumps, Pfeiffer Dry Pumps, Pfeiffer Leak Detector Repair and all other Pfeiffer Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854
