- Inlet Flange: DN 200 ISO-F
- Outlet Flange: DN 40 ISO-KF
- Pumping Speed: N2: 1250 l/s
- Compression Ratio: N2: > 1 x 108
Shopping Cart ( )
Pfeiffer HiPace 1200 U C Turbo Pump with TC 1200 Controller, Upside Down Version, Corrosive, DN 200 ISO-F, PM P03 919 / PMP03919
Condition:
New
Item#:PN06511
Mfr Part#:PM P03 919 / PMP03919
Manufacturer:Pfeiffer Vacuum
Features:
Pfeiffer HiPace 1200 U C Turbo Pump with TC 1200 Controller, Upside Down Version, Corrosive, DN 200 ISO-F, PM P03 919 / PMP03919
Pfeiffer HiPace 1200 U C Features:
- Powerful turbopump with a pumping speed of up to 1250 l/s for N2
- DN 200 ISO-F flange
- Integrated TC 1200 drive electronics with power supply
- Cooling: Water cooling
- Integrated sealing gas system with electric sealing gas valve 24 V DC
- Corrosive gas version
- Protection Class: IP54
- Interfaces: RS-485, Remote (Profibus/DeviceNet on request)
- Extensive accessories expand the range of applications
HiPace 1200 U C / PMP03919 Overview:
The Pfeiffer HiPace Series is a complete line of compact yet powerful turbo pumps featuring pumping speeds that range from 10 - 2,000 liters per second. These models are cost-effective and offer flexible installation in any orientation. The proven bearing system provides unrivaled dependability and their sophisticated rotor design makes for higher pumping speeds, higher backing pump compatibility, higher gas throughputs and good compression for light gasses.
A&J Vacuum Services offers full repair/service of Pfeiffer Vacuum Pumps, along with all other brands offered on our website. AJVS also services Pfeiffer turbo pumps and rotary vane pumps. Please contact us for information about our service and repair program or click http://www.ajvs.com/service.php to access our services page. We also offer emergency service upon request. For more information, please email A&J Vacuum Services at info@ajvs.com or call (973) 249-0854. Thank you for choosing AJVS as your supplier.
This item is non-returnable/non-refundable
Pfeiffer HiPace 1200 U C Turbo Pump with TC 1200 Controller, Upside Down Version, Corrosive, DN 200 ISO-F, PM P03 919 / PMP03919
Pfeiffer HiPace 1200 U C Technical Data:
| 253-Gas throughput at 0.1 hPa HV for CF4 | 30 hPa·l/s |
| Bearing | Hybrid |
| Compression ratio for Ar | > 1 · 108 |
| Compression ratio for CF4 | > 1 · 108 |
| Compression ratio for H2 | 6 · 103 |
| Compression ratio for He | 2 · 105 |
| Compression ratio for N2 | > 1 · 108 |
| Cooling method, standard | Water |
| Cooling water connection | G 1/4” |
| Cooling water flow | 100 l/h |
| Cooling water flow, max | 100 l/h |
| Cooling water flow, min | 100 l/h |
| Cooling water temperature | 15-35 °C | 59-95 °F | 288-308 K |
| Corrosive gas version | YES |
| Current max. | 10 A |
| Electronic drive unit | TC 1200 |
| Flange (in) | DN 200 ISO-F |
| Flange (out) | DN 40 ISO-KF |
| For electronic drive unit | TC 1200 |
| Fore-vacuum max. for N2 | 2 hPa | 1.5 Torr | 2 mbar |
| Gas throughput at 0.1 hPa HV for Ar | 26 hPa·l/s |
| Gas throughput at 0.1 hPa HV for H2 | 8 hPa·l/s |
| Gas throughput at 0.1 hPa HV for He | 15 hPa·l/s |
| Gas throughput at 0.1 hPa HV for N2 | 26 hPa·l/s |
| Gas throughput at full rotational speed for Ar | 11 hPa·l/s |
| Gas throughput at full rotational speed for CF4 | 12 hPa·l/s |
| Gas throughput at full rotational speed for H2 | > 30 hPa·l/s |
| Gas throughput at full rotational speed for He | > 30 hPa·l/s |
| Gas throughput at full rotational speed for N2 | 20 hPa·l/s |
| I/O interfaces | RS-485, Remote |
| Integrated power supply | YES |
| Mounting orientation | 90° – 180° (HV flange bottom) |
| Operating voltage: 50/60 Hz | 100 – 120 / 200 – 240, 50/60 Hz V AC |
| Particulate matter | YES |
| Permissible magnetic field max. | 6 mT |
| Power consumption max. | 1350 VA |
| Protection category | IP54 |
| Pumping speed for Ar | 1200 l/s |
| Pumping speed for CF4 | 950 l/s |
| Pumping speed for H2 | 1100 l/s |
| Pumping speed for He | 1300 l/s |
| Pumping speed for N2 | 1250 l/s |
| Rotation speed ± 2 % | 37,800 rpm | 37,800 min-1 |
| Rotation speed variable | 50 – 100 % |
| Run-up time | 2.5 min |
| Sound pressure level | ≤50 dB(A) |
| Ultimate pressure according to PNEUROP | < 1 · 10-7 hPa | < 7.5 · 10-8 Torr | < 1 · 10-7 mbar |
| Ultimate pressure without gas ballast | 1 · 10-7 hPa | 7.5 · 10-8 Torr | 1 · 10-7 mbar |
| Venting connection | G 1/8" |
| Weight | 31.9 kg | 70.33 lb |
