- Inlet Flange: DN 250 ISO-F
- Outlet Flange: DN 40 ISO-KF
- Pumping Speed: N2: 2300 l/s
- Interfaces: E74, RS-485
Shopping Cart ( )
Pfeiffer HiPace 2800 IT Turbo Pump with TC 1200 Controller, DN 250 ISO-F, 2000014745 / PM P05 241 / PMP05241
Condition:
New
Item#:PN24460
Mfr Part#:2000014745 / PM P05 241 / PMP05241
Manufacturer:Pfeiffer Vacuum
Price upon request
CONTACT US
Features:
Pfeiffer HiPace 2800 IT Turbo Pump with TC 1200 Controller, DN 250 ISO-F, 2000014745 / PM P05 241 / PMP05241
Pfeiffer HiPace 2800 IT Features:
- Powerful Turbo Pump with a pumping speed of up to 2300 l/s (N2)
- Integrated TC 1200 Drive Electronics with Power Supply
- Intelligent temperature management system
- Optimized pumping speed for light gases
- Interfaces: E74, RS-485
- Semi S2 and UL/CSA certification
- Extensive Accessories Available
HiPace 2800 IT / PMP05241 Overview:
The Pfeiffer HiPace 2800 IT is a turbo pump that is ideal for ion implantation systems. The pumping speed is optimized for light gases and the nickel-plated rotor guarantees resistivity to the dopants used in your process. The intelligent temperature management system reduces process condensation and deposits. The HiPace 2800IT / PMP05241 also has Semi S2 and UL/CSA certification.
HiPace2800IT Scope of Delivery:
- Turbopump with electronic drive unit and integrated power supply pack
- Heating jacket
- Temperature Management System (TMS box)
- Protective cover for the high vacuum connection
- Protective cover for the fore-vacuum connection
- Mating plug for the "remote" connection on the TC 1200 (type-dependent)
- Mating plug for the "E74" connection on the TC 1200 (type-dependent)
- Y-distributor M12 for the accessory connection
- Sealing gas valve (already fitted)
- Operating fluid F3 (50 ml) with syringe
- Drain nozzle
- 2 eye bolts for transport
- Corresponding coupler for cooling water connection, depending on respective pump version
- 2× 1/4” threaded hose nozzles
- 2 Swagelok couplers
- Operating instructions
HiPace2800IT Applications:
- Automotive and Transport
- Fish farming
- Metallurgy
- R&D
- Solar
- Thin Film Coating
A&J Vacuum Services offers full repair/service of Pfeiffer Vacuum Pumps, along with all other brands offered on our website. AJVS also services Pfeiffer turbo pumps and rotary vane pumps. Please contact us for information about our service and repair program or click http://www.ajvs.com/service.php to access our services page. We also offer emergency service upon request. For more information, please email A&J Vacuum Services at info@ajvs.com or call (973) 249-0854. Thank you for choosing AJVS as your supplier.
This item is non-returnable/non-refundable
Pfeiffer HiPace 2800 IT Turbo Pump with TC 1200 Controller, DN 250 ISO-F, 2000014745 / PM P05 241 / PMP05241
Pfeiffer HiPace 2800 IT Technical Data:
| Bearing | Hybrid |
| Compression ratio for Ar | > 1 · 108 |
| Compression ratio for H2 | 4 · 103 |
| Compression ratio for He | 6 · 104 |
| Compression ratio for N2 | > 1 · 108 |
| Connection flange | DN 250 ISO-F / DN 40 ISO-KF |
| Connection flange (in) | DN 250 ISO-F |
| Connection flange (out) | DN 40 ISO-KF |
| Cooling method | Water |
| Cooling water connection | In/Out: G 1/4'' |
| Cooling water flow | 100 l/h |
| Cooling water temperature | 15 – 25 °C | 59 – 77 °F | 288.15 – 298.15 K |
| Current, max. | 10 A |
| Electronic drive unit | TC 1200 |
| Emission sound pressure level (EN ISO 2151) | <50 dB(A) |
| Fore-vacuum max. for N2 | 0.8 hPa | 0.6 Torr | 0.8 mbar |
| Gas throughput at 0.1 hPa HV pressure for Ar | > 32 hPa·l/s |
| Gas throughput at 0.1 hPa HV pressure for H2 | 42 hPa·l/s |
| Gas throughput at 0.1 hPa HV pressure for He | 62 hPa·l/s |
| Gas throughput at 0.1 hPa HV pressure for N2 | > 50 hPa·l/s |
| Gas throughput at final rotational speed for Ar | 12 hPa·l/s |
| Gas throughput at final rotational speed for H2 | 75 hPa·l/s |
| Gas throughput at final rotational speed for He | 24 hPa·l/s |
| Gas throughput at final rotational speed for N2 | 18 hPa·l/s |
| Gas throughput at maximum rotation speed for Ar, heated pump at 65 °C | 9 hPa·l/s |
| Gas throughput at maximum rotation speed for Ar, heated pump at 75 °C | 6 hPa·l/s |
| Gas throughput at maximum rotation speed for H2, heated pump at 65 °C | 30 hPa·l/s |
| Gas throughput at maximum rotation speed for H2, heated pump at 75 °C | 18 hPa·l/s |
| Gas throughput at maximum rotation speed for N2, heated pump at 65 °C | 13 hPa·l/s |
| Gas throughput at maximum rotation speed for N2, heated pump at 75 °C | 7 hPa·l/s |
| I/O interfaces | E74, RS-485 |
| Input voltage(s) | 208 – 240 V AC (±10 %), 50/60 Hz |
| Integral leak rate | 1 · 10-8 Pa m³/s | 7.5 · 10-8 Torr l/s | 1 · 10-7 mbar l/s |
| Mains frequency compatibility | 50 Hz 60 Hz |
| Mounting orientation | 0° (HV flange top) – 90° |
| Permissible radial magnetic field max. | 3.4 mT |
| Position of power supply pack | Integrated power supply pack |
| Power consumption heating sleeve, max. | 1100 W |
| Power consumption max. | 1350 VA |
| Protection degree | IP20 Type 1 |
| Pumping principle | Dry |
| Pumping speed | 7560 – 10440 m³/h | 4,449.82 – 6,144.98 cfm | 126,000.25 – 174,000.35 l/min |
| Pumping speed for Ar | 2100 l/s |
| Pumping speed for H2 | 2600 l/s |
| Pumping speed for He | 2900 l/s |
| Pumping speed for N2 | 2300 l/s |
| Rotation speed variable | 50 – 100 % |
| Rotation speed ±2 % | 27300 rpm | 27,300 min-1 |
| Run-up time | 8.6 min |
| Type of electronic drive unit installation | Integrated electronic drive unit |
| Ultimate pressure | < 1 · 10-7 hPa | < 7.5 · 10-8 Torr | < 1 · 10-7 mbar |
| Venting connection | G 1/8" |
| Weight | 62 kg | 136.69 lb |
