Edwards Speedivalve SP16K Inline Valve, KF 16, Nitrile Diaphragm, C33205000
Condition:
New
Item#:PN31576
Mfr Part#:C33205000
Manufacturer:Edwards Vacuum
Features:
Edwards Speedivalve SP16K Inline Valve, KF 16, Nitrile Diaphragm, C33205000
Speedivalve SP16K Inline Valve / C33205000 Overview:
The Edwards Speedivalve SP16K is a diaphragm sealed in-line, isolation valve. The construction consists of a flexible elastomeric diaphragm which is sealed onto a polished seat by a screw mechanism. The Speedivalve's mechanism is isolated from the system by the diaphragm resulting in an extremely high-durability and ‘dirty’ system tolerant valve.
The SP10k, SP16k, SP25k, and SP40k valves are available with either fluoroelastomer or nitrile rubber diaphragms.
The valve body is made from aluminum and the complete valve is leak tight to better than 1 x 10^-6 mbar.ls^-1 and 1 bar differential.
These valves have NW flanges and are suitable for pipeline or panel mounting.
These valves are built to withstand an ambient operating temperature range of 0-40 Degrees celsius.
Edwards Speedivalve SP16K Inline Valve, KF 16, Nitrile Diaphragm, C33205000
Edwards Speedivalve SPK16K Inline Valve Technical Data:
| Connection Inlet Flange | DN 16 ISO-KF (NW16) |
| Weight | 0.240 kg | 0.529 lb |
| Valve Actuation Method | Manual |
| Connection Outlet Flange | DN 16 ISO-KF (NW16) |
| Leak Rate | 1.000 × 10⁻⁷ Pa·m³/s |
| Material Body | Aluminum |
| Material Seal | NBR (nitrile butadiene rubber) |
| Temperature Ambient Operation Max | 40.00 °C | 104.00 °F | 313.15 K |
| Temperature Ambient Operation Min | 5.00 °C | 41.00 °F | 278.15 K |
| Temperature Ambient Storage Min | -10.00 °C | 14.00 °F | 263.15 K |
| Temperature Ambient Storage Max | 40.00 °C | 104.00 °F | 313.15 K |
| Leak Rate Across Seat Valve | 1.000 × 10⁻⁷ Pa·m³/s |
| Recommended Pressure Range Max | 1500.00 mbar |
| Temperature Baking Max | 60.00 °C | 140.00 °F | 333.15 K |
Item#:PN31583
Mfr Part#:C33105800 / C331-05-800
Condition: In Stock
New
In Stock
$104.99
