- Measuring Range: 5E-10 – 1.333E3 hPa
- Mains Connection: Voltage (Range): 100 - 240 VAC
- Ambient Temperature: 5-50 °C | 41-122 °F | 278-323 K
- Number of Switch Points: 6 Pcs.
Shopping Cart ( )
Pfeiffer CenterThree Controller, for Three Gauges, 2000007116 / PT G28 330 / PTG28330
Condition:
New
Item#:PN58235
Mfr Part#:2000007116 / PT G28 330 / PTG28330
Manufacturer:Pfeiffer Vacuum
Price upon request
CONTACT US
Features:
Pfeiffer CenterThree Controller, for Three Gauges, 2000007116 / PT G28 330 / PTG28330
Pfeiffer CenterThree Controller Features:
- Measuring range: 5 · 10-10 – 1.333 · 103 mbar
- Mains connection: voltage (range) 100 - 240 VAC
- Brilliant display
- Simultaneous display of all three pressure readings
- Four configurable relay set points
- Versatile connectivity: writer, USB, Ethernet
- Direct data storage on USB flash memory (data and settings)
- Can be used as table top or as rack mount unit
CenterThree Controller / 2000007116 Overview:
Pfeiffer CenterThree Controller PT G28 330 is designed for the operation of three Center Line Gauges. The serial interface is used for communication between the CenterOne, CenterTwo and CenterThree and a computer or terminal. The user software can access the Center unit with a USB Type B or Ethernet interface.
CenterThree Scope of Delivery:
- Total pressure measuring and control unit
- Power cable (country-specific)
- 2 cable connectors (control/relay)
- 4 collar screws with synthetic nipples
- 2 rubber feet
- Rubber strip
- Operating instructions
CenterThree Applications:
- Measurement
- Monitoring
- Process control tasks
A&J Vacuum services and repairs Pfeiffer vacuum pumps, along with all other Pfeiffer hardware available on our website. Please contact us for additional information concerning our service program or click http://www.ajvs.com/service.php to access our Services page. We likewise offer emergency service and repair upon request. For more information, please contact A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
This item is non-returnable/non-refundable
Pfeiffer CenterThree Controller, for Three Gauges, 2000007116 / PT G28 330 / PTG28330
Pfeiffer CenterThree Controller Technical Data:
| Ambient temperature | 5 – 50 °C | 41 – 122 °F | 278.15 – 323.15 K |
| Connection for gauge | 3 |
| Display rate | ≥ 10 Hz |
| Error signal: switching current AC | 1 A |
| Error signal: switching current DC | 0.5 A |
| Error signal: switching voltage max. AC | 30 V |
| Error signal: switching voltage max. DC | 60 V |
| Error signal: working contact, potential-free | 1 pcs. |
| Filter time constant, rapid/normal/slow | 0.16 s / 0.8 s / 8 s |
| I/O interfaces | Writer, USB, Ethernet |
| Input voltage(s) | 100 – 240 V AC, 50/60 Hz |
| Mains frequency compatibility | 50 Hz 60 Hz |
| Measurement channel | 3 pcs. |
| Measurement range | 5E-10 – 1.333E3 hPa | 3.75 · 10-10 – 999.75 Torr | 5 · 10-10 – 1,333 mbar |
| Measurement rate | ≥ 100 Hz |
| Motor for region | Worldwide |
| Power consumption max. | 90 VA |
| Protection degree | IP30 |
| Safety | CE UL |
| Signal output: Measured value, analog | -5 – 15 V |
| Switching point number | 6 pcs. |
| Switching point: current AC | 1 A |
| Switching point: current DC | 0.5 A |
| Switching point: voltage AC | 30 V AC |
| Switching point: voltage DC | 60 V DC |
| Weight | 1.14 kg | 2.51 lb |
