- Pumping Speed (cfm): 8.2
- Ultimate Pressure (mbar): 2 x 10-3
- Inlet Flange: DN 25KF
- Exhaust Flange: DN 25KF
Shopping Cart ( )
Agilent Technologies / Varian DS 302 Dual Stage Rotary Vane Pump, Single Phase, 9499325
Condition:
Remanufactured
In Stock
Item#:PN00858
Mfr Part#:9499325
Manufacturer:Agilent Technologies / Varian
Features:
Agilent DS302 Dual Stage Rotary Vane Vacuum Pump, Hydrocarbon Oil, Single Phase, 9499325, Also known as Varian DS-302
The Agilent DS 302 / 949-9325 1Ph is a dual-stage, Rotary Vane Pump oil sealed, driven by a single-phase electric motor.
The Varian DS-302 vacuum pump works with force-feed lubrication, provided by an auxiliary gear-pump driven by the rotor of the vacuum pump itself. This ensures proper lubrication even when pressures are close to atmospheric.
The entire DS302 pump functional block is immersed in the oil contained in the casing. The oil guarantees perfect sealing of the discharge valves, enters the pump to ensure lubrication and sealing of the parts inside, facilitates heat dissipation and reduces pump noise.
The Agilent 302 vacuum pump is equipped with a special anti-suckback device which automatically isolates the vacuum system when the pump stops. This avoids rises in pressure or oil flow in the vacuum system while air is allowed back into the stator chambers. The air entering the pump after the anti-suckback device has closed prevents the oil in the casing from filling the stator chambers. The inner seals are achieved by the lubricating oil, thanks to the close machining tolerances.
A&J Vacuum Repair / Rebuild and Service Varian Agilent HS 302 and DS 302 Vacuum Pumps and Turbo Pumps along with all other Varian and Agilent Technology Vacuum Rotary Vane Pumps, Varian Dry Scroll Pump repair, Varian Leak Detector Repair and all other Pfeiffer Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854
Agilent DS302 Dual Stage Rotary Vane Vacuum Pump, Hydrocarbon Oil, Single Phase, 9499325, Also known as Varian DS-302
Free Air Displacement (l/min): 285
Pumping Speed (cfm): 8.2
Ultimate Pressure (mbar): 2 x 10-3
Rotational Speed (rpm): 1500
Inlet Flange: DN 25KF
Exhaust Flange: DN 25KF
A&J Vacuum Repair / Rebuild and Service Varian Agilent HS 302 and DS 302 Vacuum Pumps and Turbo Pumps along with all other Varian and Agilent Technology Vacuum Rotary Vane Pumps, Varian Dry Scroll Pump repair, Varian Leak Detector Repair and all other Pfeiffer Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854
Get started with your repair:
We can have a repair estimate ready for your equipment within the hour of submission.
Start your equipment repair process by creating a Service RMA.
High quality service guaranteed
A&J Vacuum Services provides repairs on all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair and Mass Spectrometer repair. Our highly trained technicians will deliver the highest quality service and satisfaction.
We operate at our own full service repair facility which allows us to quickly and economically perform all repairs in a timely manner. Our advandced machinery enables us to handle all facets of the service and repair process. AJVS utilizes industry standard vibration analysis equipment and advanced testing equipment to troubleshoot and minimize all equipment failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
AJVS repair process:
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly of the pump, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and log pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
