- Standardized DN 25 Inlet & Outlet Flanges
- Nominal Pumping Speed of 14.6 CFM at 50 Hz
- Electrically-Insulated Fold-Away Handle For Carrying Facility
- Anti-Suckback System to Ensure Stability During Shutdowns
Shopping Cart ( )
Alcatel Adixen 2021 C1 Pascal Dual Stage Rotary Vane Pump, DN 25 KF, 2000043311 / 221C1MLAS
Condition:
Remanufactured
Call us for Availability
Item#:PN20355
Mfr Part#:2000043311 / 221C1MLAS
Manufacturer:Adixen / Alcatel
Price upon request
CONTACT US
Features:
Fully Remanufactured Alcatel Adixen 2021 C1 Pascal Dual Stage Rotary Vane Pump, DN 25 KF, 2000043311 / 221C1MLAS
Product Features - Alcatel/Adixen 2021 C1 Pascal Rotary Vane Pump:
This Alcatel/Adixen 2021 C1 Pascal Dual Stage Rotary Vane Pump arrives coupled with standardized DN 25 Inlet and Outlet Flanges. The Alcatel/Adixen 2021 C1 Pascal Rotary Vane Pump has a peak pumping velocity of 6.8 cfm and a final pressure of 1 x 10^(-3) Torr. It has been thoroughly examined and can be utilized for a broad range of applications within the industrial and research industries. The Alcatel/Adixen 2021 C1 Pascal Rotary Vane Pump is corrosive and requires 1.86 kg of PFPE Operating Vacuum Fluid for maximum operating efficiency.
Additional Features - Alcatel/Adixen 2021 C1 Pascal Rotary Vane Pump
- Direct Drive Motor (For Increased Compactness)
- An electrically-insulated fold-away handle to facilitate carrying ease.
- An anti-suckback system for enhanced tightness of the pump during accidental or voluntary shutdowns.
- A Vertical Sight Glass, used for easier inspection of the oil quantity.
Pfeiffer Rotary Vane Pumps - Technical Information:
Pfeiffer Vacuum manufactures some of the most widely-utilized varieties of advanced rotary vane used in a variety of industrial applications in the twenty-first century, including laboratory processes, chemical and process engineering, among others. These products are ideally utilized for the low-to-medium intensity vacuum range. Pfeiffer vacuum pumps are especially known for their durability and wide range of application.
A rotary vane pump functions as a displacement pump, creating a low-pulsation suction volume flow. Rotary vane pumps include an eccentrically-supported rotor with two rotating vanes, encased and revolving within a housing. The Pfeiffer Rotary Vane Pumps offered to our clients are oil-lubricated (wet-version pumps); these operating fluids help to enhance the insulation of pump components and ensure maximum durability and efficiency of the product.
We offer both single-stage and dual-stage Pfeiffer Rotary Vane Vacuum Pumps on our website. Single-stage pumps are the preferred choice for low-intensity vacuum applications, while dual-stage pumps are the recommended choices for the medium and upper intensity range of vacuum applications.
A&J Vacuum services and repairs Pfeiffer Alcatel 2021 C1 Pascal Dual-Stage Rotary Vane Pumps, along with all other Pfeiffer Rotary Vane and Turbo Pumps offered on our website. Please contact us for additional information regarding our service program or visit http://www.ajvs.com/service.php to access our Services page. We likewise offer emergency service and repair upon request. If you have any questions or would like to obtain additional information, please call A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
This item is non-returnable/non-refundable
Fully Remanufactured Alcatel Adixen 2021 C1 Pascal Dual Stage Rotary Vane Pump, DN 25 KF, 2000043311 / 221C1MLAS
Pfeiffer / Adixen 2021 C1 Technical Data:
| Inlet Flange: | DN 25 |
| Outlet Flange: | DN 25 |
| Nominal Pumping Speed (50 Hz): | 14.6 cfm |
| Ultimate Pressure (closed): | 2 x 10-3 mbar |
| Ultimate Pressure (open): | 10-2 mbar |
| Water Vapor Pressure (50 Hz): | 7 mbar |
| Noise Level (50 Hz): | 50 dBA |
| Oil Capacity: | 0.98 l |
| Weight: | 67 lbs |
A&J Vacuum services and repairs Pfeiffer Alcatel 2021 C1 Pascal Dual-Stage Rotary Vane Pumps, along with all other Pfeiffer Rotary Vane and Turbo Pumps offered on our website. Please contact us for additional information regarding our service program or visit http://www.ajvs.com/service.php to access our Services page. We likewise offer emergency service and repair upon request. If you have any questions or would like to obtain additional information, please call A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
Pfeiffer Adixen Manual Instruction Pascal Series 2005, 2010, 2015, 2021 I, SD 5-21
Pfeiffer Adixen Operating Instructions Pascal Series 2005, 2010, 2015, 2021 I SD 5-21m3/h
