- P/N D1G1011150
- Flange NW 16 / KF 16
- Pressure Range: 5.000 × 10⁻⁴ mbar to 1013.00 mbar
- Pirani - thermal conductivity vacuum gauge
Shopping Cart ( )
Edwards APG200-M-NW16 Pirani Vacuum Gauge, D1G1011150
Condition:
New
Item#:PN40924
Mfr Part#:D1G1011150
Manufacturer:Edwards Vacuum
Features:
Edwards APG200-M-NW16 Pirani Vacuum Gauge, D1G1011150, APG200M
Edwards APG 200-M NW16 / D1G1011150 Overview:
The new Edwards APG 200 M is the direct replacement to the APG100-M series. This gauge is a perfect solution across a variety of applications due to compact sizing, the LED light ring, integrated set points, and reduced costs. The APG200 Pirani gauge operates on the principle of thermal conductivity in which the rate of heat loss from a heated filament is dependent on the pressure of the gas (around filament).
1. The gauge has a detachable tube that allows the replacement of the tube or electronics housing in the event of failure.
2. There is a multi-function button on the top of the gauge for navigation through the various menus within the gauge.
3. An LED indicator surrounding the circumference of the top of the gauge provides a status indication and aids the adjustment of the gauge when you navigate through the menus.
4. The gauge is available with different electrical connectors, voltage scaling and vacuum flanges to integrate with the customer process.
A&J Vacuum services and repairs Edwards Vacuum Measurement Transmitters, along with all other Edwards Vacuum and Turbo Pumps available on our website. Please contact us for additional information concerning our service program or click http://www.ajvs.com/service.php to access our Services page. We likewise offer emergency service and repair upon request. For more information, please contact A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
This item is non-returnable/non-refundable
Edwards APG200-M-NW16 Pirani Vacuum Gauge, D1G1011150, APG200M
Specifications:
| Communication Interfaces Customer | 0-10 V (analog output - linear) |
| Connection Vacuum Inlet Flange | DN 16 ISO-KF (NW16) |
| Supply Voltage | DC 15-48V |
| Principle Of Measurement | Pirani - thermal conductivity vacuum gauge |
| Pressure Measurement Min.. | 5.000 × 10⁻⁴ mbar |
| Pressure Measurement Max. | 1013.00 mbar |
| Connection Power | RJ45 (FCC 68) - Female |
Get started with your repair:
We can have a repair estimate ready for your equipment within the hour of submission.
Start your equipment repair process by creating a Service RMA.
High quality service guaranteed
A&J Vacuum Services provides repairs on all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair and Mass Spectrometer repair. Our highly trained technicians will deliver the highest quality service and satisfaction.
We operate at our own full service repair facility which allows us to quickly and economically perform all repairs in a timely manner. Our advandced machinery enables us to handle all facets of the service and repair process. AJVS utilizes industry standard vibration analysis equipment and advanced testing equipment to troubleshoot and minimize all equipment failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
AJVS repair process:
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly of the pump, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and log pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
