- Sensitivity Ranges: 5 x 10-12 atm cc/sec
- Minimum Detectable Leak: 5 x 10-12 mbar l/s
- Nominal Pumping Speed: 232 l/min
Shopping Cart ( )
Agilent Technologies VS MR15 Mobile Helium Leak Detector with DS 302 Rotary Vane Pump, 120V, G8601A
Condition:
New
Item#:PN00129
Mfr Part#:G8601A
Manufacturer:Agilent Technologies / Varian
Price upon request
CONTACT US
Features:
Agilent Technologies VS MR15 Mobile Helium Mass Spectrometer Leak Detector with DS 302 Rotary Vane Vacuum Pump, 120V, G8601A
Agilent Technologies VS MR15 Series leak detectors combine the simplicity of two-button operation with advanced system intelligence. Start and vent button permit simple day-to-day operation.
Varian VS MR15 Leak Detector offers user friendly software offers intuitive navigation to vast system capabilities. Programmable test sequences simplify daily operation, minimize operator error, and maximize production efficiency. The TFT style touch screen features high definition and brightness with wide viewing angles. Setup for worldwide use, these leak detectors can be operated in multiple languages – English, French, German, Spanish, Korean, Japanese and Chinese – and units of measure. And the VS Series conforms to CE, UL and CSA standards, assuring global acceptance.
Agilent VS MR Series Helium Leak Detectors employ Agilent’s primary pumps – rotary vane or scroll – and high vacuum pumps that deliver high inlet pumping speed and inlet pressure tolerance minimizing test cycle time and maximizing production throughput. State-of-the-art spectrometer and vacuum system design enable a broad range of test methods for specific applications. The high efficiency ion source and beam optics optimize sensitivity and mass separation, giving the VS Series very high sensitivity to meet the most stringent leak test requirements. At the same time, these leak detectors enjoy high test port pressure tolerance which permits detection of large leaks.
In addition Agilent VS MR15 Leak Detecotor offers high helium pumping speed, ensures fast system response and clean-up times.
Agilent Varian VS MR15 Primary pump and system mounting options may be selected to best suit application requirements and test environments, and the compact, lightweight design enables easy transport from one application to another.
Robust design innovations allow the Agilent VS MR 15 Series to conform to the most rigorous industrial standards and operate dependently in the most challenging environments.
A&J Vacuum Repair / Rebuild and Service Agilent Varian VS MR15 Helium Leak Detectors with DS 302 Vacuum Pump Service and Agilent Turbo Pump Service along with all other Varian and Agilent Technology Vacuum Rotary Vane Pumps, Varian Dry Scroll Pump repair, Varian Leak Detector Repair and all other Pfeiffer Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854
This item is non-returnable/non-refundable
Agilent Technologies VS MR15 Mobile Helium Mass Spectrometer Leak Detector with DS 302 Rotary Vane Vacuum Pump, 120V, G8601A
Primary Pump: DS 302
Nominal Pumping Speed: 232 l/min
Sensitivity Ranges: 5 x 10-12 atm cc/sec
Minimum Detectable Leak: 5 x 10-12 mbar l/s
Maximum Test Port Pressure: 13 mbar
Calibration: Automated or Manual (Internal or External)
Communication Interface: RS232 and analog (standard), Discrete IO (optional)
Weight: 105 kg / 230 lbs
A&J Vacuum Repair / Rebuild and Service Agilent Varian VS MR15 Helium Leak Detectors with DS 302 Vacuum Pump Service and Agilent Turbo Pump Service along with all other Varian and Agilent Technology Vacuum Rotary Vane Pumps, Varian Dry Scroll Pump repair, Varian Leak Detector Repair and all other Pfeiffer Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854
Agilent_VS_Series_Leak_Detector_Catalog.pdf
Agilent_VS_Series_Leak_Detector_Brochure.pdf
Agilent_VS_Series_Leak_Detector_Instruction_Manual.pdf
