- Fully Remanufactured
- TW 300
- 800170V2106
- DN 100 ISO flange
Shopping Cart ( )
Oerlikon Leybold TW 300 Turbo Pump, DNISO100K, 800170V2106
Condition:
Remanufactured
Call us for Availability
Item#:PN00215
Mfr Part#:800170V2106
Manufacturer:Leybold
Price upon request
CONTACT US
Features:
Oerlikon Leybold TW 300 Turbo Pump, DNISO100K, 800170V2106
Leybold TW 300 Features:
- Integrated or external frequency converter
- Compact design
- Operation in any orientation
- High foreline tolerance
- An oil-free pump for generating clean hig and ultrahigh-vacuum conditions
- Space-saver
- Easy to integrate into complex vacuum systems
- Enables the use of down-sized, foreline vacuum pumps
- Low operating costs
- Highly reliable operation
TW 300 / 800170V2106 Overview:
The TURBOVAC TW 300 and TW 300 H are turbomolecular pumps with integrated or external frequency converter. They are designed to evacuate vacuum chambers down to pressure levels in the high vacuum range. They are suitable for pumping air and clean gases. A forevacuum pump is required for their operation. The pumps have been manufactured according to the state-of-the-art and approved safety regulations. Even so in the case of improper installation or when improperly used there can be risks or damage may be caused. The TW 300 has been designed for high gas throughputs, the TW 300 H for high gas compression in the case of lighter gases.
These pumps are not suitable for
- pumping liquids or gases containing dust or particulates
- pumping corrosive, explosive or reactive gasses - operation without a forevacuum pump.
TW300 Applications:
- Mass spectrometers
- Electron beam microscopy
- Leak detectors
- R & D UHV systems
- Load locks and transfer chambers
A&J Vacuum Services offers full repair/service of Leybold Pumps, along with all other brands offered on our website. AJVS also services Leybold Turbo Pumps. Please contact us for information about our service and repair program or click http://www.ajvs.com/service.php to access our services page. We also offer emergency service upon request. For more information, please email A&J Vacuum Services at info@ajvs.com or call (973) 249-0854. Thank you for choosing AJVS as your supplier.
This item is non-returnable/non-refundable
Oerlikon Leybold TW 300 Turbo Pump, DNISO100K, 800170V2106
Leybold TW 300 Technical Data:
A&J Vacuum Services offers full repair/service of Leybold Pumps, along with all other brands offered on our website. AJVS also services Leybold Turbo Pumps. Please contact us for information about our service and repair program or click http://www.ajvs.com/service.php to access our services page. We also offer emergency service upon request. For more information, please email A&J Vacuum Services at info@ajvs.com or call (973) 249-0854. Thank you for choosing AJVS as your supplier.
Get started with your repair:
We can have a repair estimate ready for your equipment within the hour of submission.
Start your equipment repair process by creating a Service RMA.
High quality service guaranteed
A&J Vacuum Services provides repairs on all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair and Mass Spectrometer repair. Our highly trained technicians will deliver the highest quality service and satisfaction.
We operate at our own full service repair facility which allows us to quickly and economically perform all repairs in a timely manner. Our advandced machinery enables us to handle all facets of the service and repair process. AJVS utilizes industry standard vibration analysis equipment and advanced testing equipment to troubleshoot and minimize all equipment failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
AJVS repair process:
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly of the pump, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and log pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
We can repair your:
- Turbo Pumps
- Rotary Vane Pumps
- Dry Vacuum Pumps
- Leak Detectors
- Scroll Dry Pumps
- Vacuum Boosters
- Diaphragm Dry Pumps
