Pfeiffer IKT 010, Digital Cold Cathode Sensor, Low Current, DN 25, 2000005698 / PT R72 550 / PTR72550
Condition:
New
Item#:PN54890
Mfr Part#:2000005698 / PT R72 550 / PTR72550
Manufacturer:Pfeiffer-Vacuum
Price upon request
CONTACT US
Features:
Pfeiffer IKT 010, Digital Cold Cathode Sensor, Low Current, DN 25, 2000005698 / PT R72 550 / PTR72550
Pfeiffer IKT 010 Features:
- Input voltages: 5 VDC
- Pressure max.: 10000 mbar
- Wire to HiPace Neo
- Low magnetic stray field
- Compact dimensions
- Optimized for applications in medium and high vacuum range
- Display range: 1 · 10-8-1 · 10-2 hPa
IKT 010 / PTR72550 Overview:
The IKT 010 is intended to be wired to the HiPace Neo. An additional measurement cable is not required.
A&J Vacuum repair / rebuild and service Pfeiffer HiPace 10, HiPace 30, Hipace 80, Hipace 300, Hipace 700 Turbo Pumps, PMP03940 Pfeiffer Backing Pumps along with all other Pfeiffer Vacuum Pumps and all other Pfeiffer Leak Detector Service and repair. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
Pfeiffer IKT 010, Digital Cold Cathode Sensor, Low Current, DN 25, 2000005698 / PT R72 550 / PTR72550
Pfeiffer IKT 010 Technical Data:
| Ambient temperature | 5 – 55 °C | 41 – 131 °F | 278.15 – 328.15 K |
| Anode | Mo |
| Bakeout temperature max.(electronics removed) | ≤ 150 °C | ≤ 302 °F | ≤ 423.15 K |
| Connection flange | DN 25 ISO-KF |
| Connection flange (in) | DN 25 ISO-KF |
| Feedthrough | Glass |
| Flange, material | Stainless Steel 1.4435 (AISI 316L) |
| Input voltage(s) | 5 V DC |
| Interface: Connection, device side | Cable with Micro-USB-connector for HiPace Neo |
| Materials in contact with media | Stainless steel 1.4435 (AISI 316L) Stainless steel 1.4310 (AISI 301) Molybdenum Glass Titanium |
| Measurement cable length | 0.5 m |
| Measuring accuracy | 30 % (5E-8 hPa – 1E-2 hPa) |
| Measuring range | 5E-8 – 1E-2 hPa | 3.75 · 10-8 – 7.5 · 10-3 Torr | 5 · 10-8 – 1 · 10-2 mbar |
| Power consumption max. | 2 W |
| Pressure max. | 1 · 104 hPa | 7,500 Torr | 10,000 mbar |
| Protection degree | IP40 |
| Repeatability | 5 % (5E-8 hPa – 1E-2 hPa) |
| Seal | Metal |
| Special feature | Low current version |
| Volume | 19.9 cm³ |
| Weight | 0.28 kg | 0.62 lb |
| Wire to | HiPace Neo |
