- Final Pressure: < 0.5 mbar
- Exhaust Pressure Max: 1100 hPa
- Pumping Speed 0.6 m3/h
- Rotational Speed (60 Hz): 1800 rpm
Shopping Cart ( )
Pfeiffer MVP 015-4 Remanufactured Diaphragm Vacuum Pump, Pumping Speed 0.6 m3/h, 120 V (+ 5 % /- 10 %), 60 Hz, PK T05 064 A / PKT05064A
Condition:
Remanufactured
In Stock
Item#:PN57725
Mfr Part#:PK T05 064 A / PKT05064A
Manufacturer:Pfeiffer Vacuum
Features:
Pfeiffer MVP 015-4 Remanufactured Diaphragm Vacuum Pump, Pumping Speed 0.6 m3/h, 120 V (+ 5 % /- 10 %), 60 Hz, PK T05 064 A / PKT05064A
MVP 015-4 / PKT05064A Overview:
The remanufactured Pfeiffer MVP 015-4 Diaphragm Pump can be applied in all areas where an oil-free, dry vacuum is required. Particularly the pump is suitable as backing pump for many Pfeiffer Vacuum turbo pumps in applications involving light gas loads only.
MVP015-4 Applications:
- Pumping Stations
- Plants
- Research
- Laboratories
- Analytical
- Chemistry
- Leak Detection
A&J Vacuum repairs, rebuilds, and services Pfeiffer Vacuum Pumps, including Diaphragm Pumps and Turbo Pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
This item is non-returnable/non-refundable
Pfeiffer MVP 015-4 Remanufactured Diaphragm Vacuum Pump, Pumping Speed 0.6 m3/h, 120 V (+ 5 % /- 10 %), 60 Hz, PK T05 064 A / PKT05064A
Pfeiffer MVP 015-4 Technical Data:
- Ambient temperature: 12-40 °C | 53.6-104 °F | 285-313 K
- Cooling method, standard: Convection cooled
- Current max.: 2.9 A
- Emission sound pressure level without gas ballast or purge: 52 dB(A)
- Exhaust pressure, max.: 1,100 hPa | 825 Torr | 1,100 mbar
- Flange (in): DN 16 ISO-KF; G 1/8"
- Flange (out): G 1/8” with silencer
- Intake pressure max.: 1,100 hPa | 825 Torr | 1,100 mbar
- Leak rate: ≤ 5 · 10-4 Pa m3/s | ≤ 3.75 · 10-3 Torr l/s | ≤ 5 · 10-3mbar l/s
- Mains cable: Yes
- Mains requirement - voltage: 120 V
- Mains requirement - voltage (range): ± 10 %
- Motor version: 1-ph motor
- Number of pumping stages: 4
- Operating altitude, max.: 2000 m
- Protection category: IP54
- Pumping speed at 60 Hz: 0.6 m³/h | 0.35 cfm | 10 l/min
- Rated current absorption: 0.8 A
- Rotation speed at 60 Hz: 1,800 rpm | 1,800 min-1
- Sound pressure level: 52 dB(A)
- Switch New: No
- Temperature - storage: 5-40 °C | 41-104 °F | 278-313 K
- Ultimate pressure without gas ballast: 5 · 10-1 hPa | 3.75 · 10-1Torr | 5 · 10-1 mbar
- Weight: 7.5 kg | 16.53 lb
A&J Vacuum repairs, rebuilds, and services Pfeiffer Vacuum Pumps, including Diaphragm Pumps and Turbo Pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
Item#:PN07431
Mfr Part#:2000005857 / PU E22 009 -T / PUE22009-T
Condition: In Stock
New
In Stock
$706.50
Item#:PN20389
Mfr Part#:49359
Condition: In Stock
New
In Stock
$84.00
Item#:PN22764
Mfr Part#:2000025266 / PK 050 272 -T / PK050272-T
Condition: Ships Within 1-3 Days
New
$498.00
Item#:PN15316
Mfr Part#:2000029578 / P 0920 567 E / P0920567E
Condition: In Stock
New
In Stock
$81.00
Item#:PN15592
Mfr Part#:PN15592
Condition: In Stock
New
In Stock
$65.00
Item#:PN15671
Mfr Part#:2000029603 / P 0920 739 E / P0920739E
Condition: In Stock
New
In Stock
$165.00
Item#:PN16095
Mfr Part#:2000025222 / PK 050 108 -T / PK050108-T
Condition: In Stock
New
In Stock
$146.00
Item#:PN22766
Mfr Part#:2000018251 / PM 071 282 -X / PM071282-X
Condition: Ships Within 1-3 Days
New
$852.00
Get started with your repair:
We can have a repair estimate ready for your equipment within the hour of submission.
Start your equipment repair process by creating a Service RMA.
High quality service guaranteed
A&J Vacuum Services provides repairs on all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair and Mass Spectrometer repair. Our highly trained technicians will deliver the highest quality service and satisfaction.
We operate at our own full service repair facility which allows us to quickly and economically perform all repairs in a timely manner. Our advandced machinery enables us to handle all facets of the service and repair process. AJVS utilizes industry standard vibration analysis equipment and advanced testing equipment to troubleshoot and minimize all equipment failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
AJVS repair process:
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly of the pump, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and log pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
We can repair your:
- Turbo Pumps
- Rotary Vane Pumps
- Dry Vacuum Pumps
- Leak Detectors
- Scroll Dry Pumps
- Vacuum Boosters
- Diaphragm Dry Pumps
