- Universal Control for Products including Pfeiffer RS-485 Protocol
- 24 VDC Input Voltage
- 18 W Power Consumption Max
- IP20 Protection Degree
Shopping Cart ( )
Pfeiffer OmniControl 001 Mobile, Control Units with One Data Option, 2000026663 / PE D22 000 0 / PED220000
Condition:
New
Item#:PN49060
Mfr Part#:2000026663 / PE D22 000 0 / PED220000
Manufacturer:Pfeiffer-Vacuum
Price upon request
CONTACT US
Features:
Pfeiffer OmniControl 001 Mobile, Control Units with One Data Option, 2000026663 / PE D22 000 0 / PED220000
Pfeiffer OmniControl 001 Mobile Features:
- Universal control unit for all products with Pfeiffer Vacuum RS-485 protocol
- Easy operation on 3.5'' touchscreen display
- Simple data acquisition and processing between Pfeiffer Vacuum units
- Respective modules define the scope of functions
OmniControl 001 Mobile / PED220000 Overview:
With the OmniControl, you only need one control device for your complete vacuum system. The device combines control of the total pressure with control of the pumps. Data exchange and processing between Pfeiffer Vacuum products is thus very uncomplicated and without the need to purchase additional devices. The OmniControl controls products that support a Pfeiffer Vacuum RS-485 protocol (e.g. HiPace, HiScroll, HiLobe, MVP und DigiLine). In addition, ActiveLine gauges (with analog output) can be connected as an option.
The RS-485 interface and the connecting socket designated "gauge" on the gauge/IO option are used to connect a Pfeiffer Vacuum gauge.
OmniControl Mobile Scope of Delivery:
- OmniControl control unit (optionally with bench holder installed)
- Operating instructions
- Fixing materials
OmniControl Mobile Applications:
- Semiconductor manufacturing
- Coating technology
- Research and development
A&J Vacuum Services repairs / rebuilds and services all of the Pfeiffer HiScroll pumps such as the HiScroll 6 / PD S10 000, HiScroll 12 / PD S20 000, HiScroll 18 / PD S30 000, and HiScroll 46 / PD S40 000 as well as other Pfeiffer Vacuum equipment such as their turbomolecular pumps, rotary vane pumps, leak detectors, and more. Please contact us for information about our service program or click here http://www.ajvs.com/service.php to go to our service page. We also offer emergency rush service upon request. For more information please contact A&J Vacuum Services at 973-249-0854.
This item is non-returnable/non-refundable
Pfeiffer OmniControl 001 Mobile, Control Units with One Data Option, 2000026663 / PE D22 000 0 / PED220000
Pfeiffer OmniControl 001 Mobile Technical Data:
| Ambient temperature | 0 – 50 °C | 32 – 122 °F | 273.15 – 323.15 K |
| Input voltage(s) | 24 V DC |
| Module Slot 1 | Data |
| Power consumption max. | 18 W |
| Protection degree | IP20 |
| Weight | 0.3 kg | 0.66 lb |
A&J Vacuum Services repairs / rebuilds and services all of the Pfeiffer HiScroll pumps such as the HiScroll 6 / PD S10 000, HiScroll 12 / PD S20 000, HiScroll 18 / PD S30 000, and HiScroll 46 / PD S40 000 as well as other Pfeiffer Vacuum equipment such as their turbomolecular pumps, rotary vane pumps, leak detectors, and more. Please contact us for information about our service program or click here http://www.ajvs.com/service.php to go to our service page. We also offer emergency rush service upon request. For more information please contact A&J Vacuum Services at 973-249-0854.
Pfeiffer OmniControl Communication Guide Operation Manual
Pfeiffer OmniControl DATA Supplementary Information
Pfeiffer OmniControl Operation Manual
Pfeiffer OmniControl DATA Operation Manual
