Pfeiffer PrismaPro® QMG 250 M1, 1 – 100 u, Compact Mass Spectrometer System, Open Ion Source, Iridium Coated with Y2O3 Filament, 2000007326 / PTM16112210 / PT M16 112 210

Pfeiffer PrismaPro® QMG 250 M1, 1 – 100 u, Compact Mass Spectrometer System, Open Ion Source, Iridium Coated with Y2O3 Filament, 2000007326 / PTM16112210 / PT M16 112 210

Pfeiffer PrismaPro QMG 250 M1 Features:

• Tungsten Filament
• Standard Interface
• Bakeout Temperature: analyzer 300°C
• PV MassSpec software for Windows 10, 8.1 & 7 for recording, saving and displaying measured data
• Leak detection and residual gas analysis routines launces by a simple mouse-click
• Determination of gas concentrations by means of integrated matrix calculation
• Operating pressure max.: C-SEM 5 · 10-5 hPa | 3.75 · 10-5 Torr | 5 · 10-5 mbar
• Operating pressure max.: Faraday 5 · 10-4 hPa | 3.75 · 10-4 Torr | 5 · 10-4 mbar
• Operating pressure max.: SEM 5 · 10-5 hPa | 3.75 · 10-5 Torr | 5 · 10-5 mbar
• Easy definition of measurement recipes
• Ethernet networking
• Ambient temperature: analyzer  150 °C | 302 °F | 423 K
• Bakeout temperature: analyzer  300 °C | 572 °F | 573 K

PrismaPro QMG 250 M1 / 2000007326 Overview:

The Pfeiffer PrismaPro® mass spectrometer is designed for partial pressure analysis at pressures < 10-4 mbar. Typical applications are measurement, monitoring and process control functions in vacuum systems.
