Pfeiffer TPH 510 C Plasma Corrosive Turbo Pump, ISO 160, PMP01381 / PM P01 381
Condition:
Remanufactured
Call us for Availability
Item#:PN00160
Mfr Part#:PMP01381 / PM P01 381
Manufacturer:Pfeiffer Vacuum
Price upon request
CONTACT US
Features:
Pfeiffer TPH 510 C Plasma Corrosive Turbo Pump, ISO 160, PMP01381 / PM P01 381
TPH 510 C / PMP01381 Overview:
Fully Refurbished Pfeiffer Vacuum TPH 510C Plasma Corrosive Turbo Pump with an ISO 160 Inlet Flange and KF 40 Outlet Flange.
This pump has a free of wear permanent magnetic bearing at the high vacuum side and an oil lubricated ceramic bearing at the backing side. The Turbo Pumps TMH and TMU models are identical in terms of design, they only differ in their intake flange. This pump has been thoroughly tested and is ready for a wide range of applications in the research industry.
TPH510C Applications:
- Freeze drying - packaging industry
- Corrosive Applications
- Degassing, casting, dry vacuum smelting (super-pure metals)
- Incandescent lamp manufacturing
- Electronic tubes
- Thin film deposition
- Space simulation
- Cryogenic research
- Electron microscopy
- Nuclear physics, Plasma physics, High energy physics
- Particle accelerators - Storage rings
A&J Vacuum also repair / rebuild and service Pfeiffer TPH 510 C Plasma / PM P01 381 Turbo Pumps along with all other Pfeiffer Vacuum pumps and Pfeiffer Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
This item is non-returnable/non-refundable
Pfeiffer TPH 510 C Plasma Corrosive Turbo Pump, ISO 160, PMP01381 / PM P01 381
Pfeiffer TPH 510 C Technical Data:
| TPU 510 | ||
| Intake flange | DN 160 ISO | |
| Fore-vacuum flange | DN 40 KF | |
| Volume flow rate | ||
| N2 | l/s | 500 |
| He | l/s | 570 |
| H2 | l/s | 500 |
| Rec Backing Pump | 12 | |
| Acc electronic drive unit | TCP 300 (TCP 300),TCP 310 (TCP 310),TCP 380 | |
| Compression ratio | ||
| N2 | 8x10^8 | |
| He | 1.5x10^4 | |
| H2 | 1x10^3 | |
| Ultimate pressure | mbar | 10^-11 |
| Ultimate operating | mbar | <1x10^-10 |
| Pressure | mbar | <1x10^-9 |
| 3 | mbar | <1x10^-8 |
| Speed | rpm | 60,000 |
| Start-up time with TCP 300 (TCP 300)/310 | min | 6 |
| Start-up time with TCP 120 (TCP 120)/121 | min | |
| Permissible magnetic field | mT | 6 |
| Oil filling | cm^3 | 2x10 |
| Cooling water req | l/h | 15 |
| Cooling water temperature | C | 5-25 |
| Permissible ambient temperature for air cooing | C | 0-35 |
| Power input of heater | Watt | 250 |
| weight | kg | 30 |
A&J Vacuum also repair / rebuild and service Pfeiffer TPH 510 C Plasma / PM P01 381 Turbo Pumps along with all other Pfeiffer Vacuum pumps and Pfeiffer Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
Get started with your repair:
We can have a repair estimate ready for your equipment within the hour of submission.
Start your equipment repair process by creating a Service RMA.
High quality service guaranteed
A&J Vacuum Services provides repairs on all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair and Mass Spectrometer repair. Our highly trained technicians will deliver the highest quality service and satisfaction.
We operate at our own full service repair facility which allows us to quickly and economically perform all repairs in a timely manner. Our advandced machinery enables us to handle all facets of the service and repair process. AJVS utilizes industry standard vibration analysis equipment and advanced testing equipment to troubleshoot and minimize all equipment failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
AJVS repair process:
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly of the pump, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and log pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
