Pfeiffer Uno 6 Rotary Vane Pump, Single Phase Motor, 100 - 115/200 - 230 V, 50/60 Hz, 2000093077 / PK D070 010 C0 A / PKD070010C0A

Pfeiffer Uno 6 Features:

• Integrated GB and safety valve
• Pumping speed of 2.83 CFM at 50 Hz and 3.41 CFM at 60 Hz
• Ultimate pressure of 0.5 mbar with GB
• High performance single-stage pump
• Compact design

Uno 6 / PKD070010C0A Overview:

The rotary vane pumps are single-stage, oil-sealed, rotary positive displacement pumps designed for applications in the coarse and medium vacuum range. They are offered in a standard version with a conventional shaft seal, or as an M version featuring a non-contact, wear-free magnetic coupling drive. The pump housing is hermetically sealed.

A built-in gas ballast system allows controlled introduction of ambient air or inert gas into the suction chamber. This helps minimize condensate formation within the pumping system.

These rotary vane pumps are also equipped with a vacuum safety valve, which isolates the pump from the vacuum chamber during intentional or unintentional shutdowns. It vents the pumping system using displaced gas to prevent oil from backstreaming into the vacuum chamber. Upon startup, the valve opens after a short delay.

Accessory cable has to be ordered separately.

Uno6 Scope of Delivery:

• Rotary vane vacuum pump with motor
• Operating fluid
• Centering ring with cone sieve and O-ring for the vacuum flange
• Centering ring with nozzle and O-ring for the exhaust flange
• Locking caps for both connection flanges
• Operating instructions

Uno6 Applications:

• Research & Development
• Scientific instruments
• Medical
• Metallurgy
• Thin film coating
• Pharma and biotech
• Leak detection

A&J Vacuum Repairs / Rebuilds and Services all Pfeiffer UnoLine rotary vane pumps including all other Pfeiffer vacuum pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.

Pfeiffer UNO 6 Rotary Vane Vacuum Pump, 100V, 50 Hz | 95 - 105V, 60 Hz, PK D07 708 / PKD07708

Pfeiffer Uno 6 Features:

• Integrated GB and safety valve
• Pumping speed of 2.83 CFM at 50 Hz and 3.41 CFM at 60 Hz
• Ultimate pressure of 0.5 mbar with GB
• High performance single-stage pump
• Compact design

Uno 6 / PKD07708 Overview:

The rotary vane pumps are single-stage, oil-sealed, rotary positive displacement pumps designed for applications in the coarse and medium vacuum range. They are offered in a standard version with a conventional shaft seal, or as an M version featuring a non-contact, wear-free magnetic coupling drive. The pump housing is hermetically sealed.

A built-in gas ballast system allows controlled introduction of ambient air or inert gas into the suction chamber. This helps minimize condensate formation within the pumping system.

These rotary vane pumps are also equipped with a vacuum safety valve, which isolates the pump from the vacuum chamber during intentional or unintentional shutdowns. It vents the pumping system using displaced gas to prevent oil from backstreaming into the vacuum chamber. Upon startup, the valve opens after a short delay.

Accessory cable has to be ordered separately.

Uno6 Scope of Delivery:

• Rotary vane vacuum pump with motor
• Operating fluid
• Centering ring with cone sieve and O-ring for the vacuum flange
• Centering ring with nozzle and O-ring for the exhaust flange
• Locking caps for both connection flanges
• Operating instructions

Uno6 Applications:

• Research & Development
• Scientific instruments
• Medical
• Metallurgy
• Thin film coating
• Pharma and biotech
• Leak detection

A&J Vacuum Repairs / Rebuilds and Services all Pfeiffer UnoLine rotary vane pumps including all other Pfeiffer vacuum pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.

Pfeiffer UNO 6 Rotary Vane Vacuum Pump, 105 V (50 Hz), 115-125 V (60 Hz), 2000022999 / PK D07 707 / PKD07707

Power cable is not included. Please view the accessories tab for compatible cables.

Product Overview:

The Pfeiffer UNO 6 Vacuum Pump is a direct replacement and update over the now-obsolete Pfeiffer UNO 2.5 Vacuum Pump. The DUO 6 series of Pfeiffer Rotary Vane vacuum pumps incorporates oil-stage lubrication and a two-stage operating mechanism.

Our Pfeiffer UNO 6 vacuum pumps are likewise equipped with a high vacuum safety valve. This valve mechanism tightly seals the vacuum chamber while the pump is operating at standstill mode, while simultaneously allowing for ventillation of the pump.

Pfeiffer UNO 6 Rotary Vane Pump Key Features & Attributes:

• Dual-stage, high-performance rotary vane pump with a pumping speed of 4.8 m3/h at 50 Hz / 5.8 m3/h at 60 Hz
• With single-phase motor with C14 connector plug inside the terminal box
• Integrated gas ballast and HV safety valve
• For all low and medium vacuum applications
• Optional with magnetic coupling
• Other motor voltages available on request

Pfeiffer UNO 6 Dimensions:

A: 309 mm

B: 319 mm

C: 123 mm

D: 176 mm

E: 85.5 mm

A&J Vacuum services and repairs Pfeiffer Uno, along with all other Pfeiffer Vacuum and Turbo Pumps available on our website. Please contact us for additional information concerning our service program or click http://www.ajvs.com/service.php to access our Services page. We likewise offer emergency service and repair upon request. For more information, please contact A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.

Pfeiffer Uno 6 Rotary Vane Vacuum Pump, 115V, 50/60 Hz, DN 16 ISO-KF, 2000023010 / PK D070 010 B0 A / PKD070010B0A

Pfeiffer Uno 6 Features:

• Integrated GB and safety valve
• Pumping speed of 2.83 CFM at 50 Hz and 3.41 CFM at 60 Hz
• Ultimate pressure of 0.5 mbar with GB
• High performance single-stage pump
• Compact design

Uno 6 / PKD070010B0A Overview:

The rotary vane pumps are single-stage, oil-sealed, rotary positive displacement pumps designed for applications in the coarse and medium vacuum range. They are offered in a standard version with a conventional shaft seal, or as an M version featuring a non-contact, wear-free magnetic coupling drive. The pump housing is hermetically sealed.

A built-in gas ballast system allows controlled introduction of ambient air or inert gas into the suction chamber. This helps minimize condensate formation within the pumping system.

These rotary vane pumps are also equipped with a vacuum safety valve, which isolates the pump from the vacuum chamber during intentional or unintentional shutdowns. It vents the pumping system using displaced gas to prevent oil from backstreaming into the vacuum chamber. Upon startup, the valve opens after a short delay.

Accessory cable has to be ordered separately.

Uno6 Scope of Delivery:

• Rotary vane vacuum pump with motor
• Operating fluid
• Centering ring with cone sieve and O-ring for the vacuum flange
• Centering ring with nozzle and O-ring for the exhaust flange
• Locking caps for both connection flanges
• Operating instructions

Uno6 Applications:

• Research & Development
• Scientific instruments
• Medical
• Metallurgy
• Thin film coating
• Pharma and biotech
• Leak detection

A&J Vacuum Repairs / Rebuilds and Services all Pfeiffer UnoLine rotary vane pumps including all other Pfeiffer vacuum pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.

Pfeiffer Uno 6 Rotary Vane Vacuum Pump, 200 V, 50 Hz | 208 V, 60 Hz, PK D07 709 / PKD07709

Pfeiffer Uno 6 Features:

• Integrated GB and safety valve
• Pumping speed of 2.83 CFM at 50 Hz and 3.41 CFM at 60 Hz
• Ultimate pressure of 0.5 mbar with GB
• High performance single-stage pump
• Compact design

Uno 6 / PKD07709 Overview:

The rotary vane pumps are single-stage, oil-sealed, rotary positive displacement pumps designed for applications in the coarse and medium vacuum range. They are offered in a standard version with a conventional shaft seal, or as an M version featuring a non-contact, wear-free magnetic coupling drive. The pump housing is hermetically sealed.

A built-in gas ballast system allows controlled introduction of ambient air or inert gas into the suction chamber. This helps minimize condensate formation within the pumping system.

These rotary vane pumps are also equipped with a vacuum safety valve, which isolates the pump from the vacuum chamber during intentional or unintentional shutdowns. It vents the pumping system using displaced gas to prevent oil from backstreaming into the vacuum chamber. Upon startup, the valve opens after a short delay.

Accessory cable has to be ordered separately.

Uno6 Scope of Delivery:

• Rotary vane vacuum pump with motor
• Operating fluid
• Centering ring with cone sieve and O-ring for the vacuum flange
• Centering ring with nozzle and O-ring for the exhaust flange
• Locking caps for both connection flanges
• Operating instructions

Uno6 Applications:

• Research & Development
• Scientific instruments
• Medical
• Metallurgy
• Thin film coating
• Pharma and biotech
• Leak detection

A&J Vacuum Repairs / Rebuilds and Services all Pfeiffer UnoLine rotary vane pumps including all other Pfeiffer vacuum pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
