Edwards ESDP 12 Dry Scroll Vacuum Pump Major Repair / Rebuild Kit, P71005800, ESDP12
Condition:
New
Item#:PN01505
Mfr Part#:P71005800
Manufacturer:Edwards Vacuum
Features:
Edwards ESDP12 Dry Scroll Vacuum Pump Major Repair / Rebuild Kit, P71005800, A71005800, ESDP-12
Edwards ESDP12 Overview:
The Edwards Vacuum ESDP12 Major Repair / Rebuild Kit includes everything needed for major overhauls on the Edwards Vacuum ESDP12 Dry Scroll Vacuum Pump.
We also do minor and major repairs for all Edwards Vacuum Dry Scroll Vacuum Pumps.
Edwards Vacuum ESDP12 Major Repair / Rebuild Kit A71005800, P71005800
Edwards Vacuum ESDP 12, Major Repair / Rebuild Kit contains the following parts:
| DESCRIPTION | PART NO. | QTY |
|
Bearing Needle 6302ZZ, PFPE |
330007 |
1 |
|
Bearing Needle Scroll PFPE |
08880021 |
2 |
|
Bearing Needle Scroll PFPE |
08884002 |
2 |
|
Bearing Needle Scroll PFPE |
08884011 |
1 |
|
Coupling Sox, Open Center |
670086120 |
1 |
|
19 Grease Tec,. 5 oz tube |
870014 |
1 |
|
Washer Thrusti, 1.09 X .6 X .04 |
420038 |
1 |
|
Screw Phillips, "Truss Head" |
400033 |
4 |
|
O Ring Buna, 11.6 X 2.4 MM |
02120033 |
1 |
|
O Ring Viton, 11 X 1.5 MM |
02122009V |
4 |
|
O Ring Viton, 220 X 3 MM |
06995974 |
1 |
|
O Ring Viton, 45 X 3 MM |
Pl23970304 |
1 |
|
Ring Retaining MI7, 472, S/S |
470014 |
1 |
|
Crank Pin Single |
71002006S |
2 |
|
G-Seal, FS-1, Scroll Pump |
08883002 |
1 |
|
G-Seal, FS-2, Scroll Pump |
08883005 |
1 |
|
G-Seal, OS Scroll Pump |
08883001 |
2 |
|
Seal Shaft, FS-1, Scroll Pump |
08883004 |
1 |
|
Seal Shaft, FS-2, Scroll Pump |
08883003 |
1 |
|
Tip Seals, ESDPI2 |
A71002026 |
1 |
|
Spring |
08801050 |
1 |
|
Spring Exhaust Valve, ESDP30A |
08804390 |
1 |
|
Guide Outlet Valve |
08805042 |
1 |
|
Valve Exhaust Stem |
08805381 |
1 |
|
Screw Washer head. M3x4mm steel |
400068 |
1 |
THERE ARE NO RETURNS ON THIS PRODUCT.
A&J Vacuum Repair / Rebuild and Service Varian EDWARDS EDSP SCROLL PUMPS, XDS Pumps and all Scroll pump service along with all other EdwardsVacuum Rotary Vane Pumps, Edwards Turbomolecular Pumps repair, Edwards Leak Detector Repair and all other Edwards Vacuum pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854
This item is non-returnable/non-refundable
