- VBC Microtorr 11 / Alcatel 2005 SD
- Ultimate Vacuum 9x10-6 Torr
- Diffusion Pump Speed 11 Liters/Sec.
- Airborne noise emission level Less than 70 dBA
Shopping Cart ( )
VBC Microtorr 11D Integrated Diffusion Pump System with Alcatel 2005 SD Series Vacuum Pump with Diffusion Pump, Set to 115 VAC
Condition:
Remanufactured
Call us for Availability
Item#:PN21281
Mfr Part#:VBC Microtorr
Manufacturer:Adixen / Alcatel
Features:
Vacuum Barrier Corporation Microtorr 11D Integrated Diffusion Pump System with Alcatel 2005 SD Series Vacuum Pump with Diffusion Pump, Set to 115 VAC
VBC Microtorr 11D Overview:
Fully Refurbished VBC Microtorr11 Diffusion Pump System with Alcatel 2005 SD Dual Stage Rotary Vane Pump coupled with a KF-25 Inlet Flange and KF-25 Outlet Flange. This Alcatel Rotary Vane Pump has a peak pumping velocity of 3.2 cfm and a final pressure of 1 x 10-3 Torr. It has been thoroughly examined and is ready for broad range of applications within the research and industrial industries.
This unit consists of a two-stage mechanical forepump, air-cooled oil diffusion pump and cooling fan, all assembled on a small base which includes rubber vibration isolators.
Microtorr 11 is a small, highly reliable, high vacuum pumping station. Primary use of the MICROtorr 11 is for the maintenance of an insulating vacuum in SEMIFLEX cryogenic pipe systems. It is a complete unit requiring only connection to the annulus of the system to be evacuated, and an appropriate source of electric power.
VBC Microtorr 11D Applications:
- Gas analyzers
- Leak detection
- Mass spectrometers
- Other spectrometers
- Electron microscopes
- Surface analyzers
- Centrifuges
- Sterilization
- Electron tubes
- Lamps
- TV tubes (CRT)
- Refrigeration
- Air conditioning
- Drying
- Distillation
- Metallurgy
- Free drying
- CVD.LPCVD
- Ion implantation
- Dry etching
- Load-lock
- Cryogenics
- Gas recovery
- Oxygen pumping
VBC Microtorr 11D Dimensions:
A&J Vacuum Rrepair / Rebuild and Service Alcatel 2005 SD Vacuum Pumps , Vacuum Barrier Corporation Systems, Alcatel Turbo Vacuum pumps, Alcatel Turbo Pumping Stations along with all other VBC Alcatel Turbo Pump Service and repair. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854
Vacuum Barrier Corporation Microtorr 11D Integrated Diffusion Pump System with Alcatel 2005 SD Series Vacuum Pump with Diffusion Pump, Set to 115 VAC
VBC Microtorr 11D Technical Data:
| Peak Pumping Speed: | 3.4 cfm |
| Diffusion Pumping Speed: | 11 liters/sec |
| Inlet Flange | KF-25 |
| Outlet Flange | KF-25 |
| Ultimate pressure | 9 x 10-6 Torr. |
| 115-220 Volts, 60 Hz, | 8.2 - 4.3amps |
| Oil - Mechanical Pump - Capacity . | .83 Liters |
| Oil - Diffusion Pump - Capacity | 55 cc. |
| Power | 950 Watts |
Item#:PN05858
Mfr Part#:Elite Z
Condition: In Stock
New
In Stock
$34.95
Item#:PN07559
Mfr Part#:KF25CLA
Condition: In Stock
New
In Stock
$10.25
Item#:PN17698
Mfr Part#:EF-FG10-KF25
Condition: In Stock
New
In Stock
$325.00
Get started with your repair:
We can have a repair estimate ready for your equipment within the hour of submission.
Start your equipment repair process by creating a Service RMA.
High quality service guaranteed
A&J Vacuum Services provides repairs on all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair and Mass Spectrometer repair. Our highly trained technicians will deliver the highest quality service and satisfaction.
We operate at our own full service repair facility which allows us to quickly and economically perform all repairs in a timely manner. Our advandced machinery enables us to handle all facets of the service and repair process. AJVS utilizes industry standard vibration analysis equipment and advanced testing equipment to troubleshoot and minimize all equipment failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
AJVS repair process:
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly of the pump, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and log pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
We can repair your:
- Turbo Pumps
- Rotary Vane Pumps
- Dry Vacuum Pumps
- Leak Detectors
- Scroll Dry Pumps
- Vacuum Boosters
- Diaphragm Dry Pumps
