- This model is discontinued.
Shopping Cart ( )
Adixen Drytel 1025 Dry Vacuum Turbo Pumping Station, AMD4 Dry Vacuum Pump with MDP5011, D025AULPS710
Condition:
Discontinued
Item#:PN07298
Mfr Part#:D025AULPS710
Manufacturer:Adixen / Alcatel
This product has been discontinued and is no longer available for sale
VIEW REPLACEMENT
Features:
Adixen Drytel 1025 Dry Vacuum Turbo Pumping Station, AMD4 Dry Vacuum Pump with MDP5011, D025AULPS710
This model is obsolete without a direct replacement. The closest alternative is a HiCube 80 Eco with an MVP030-3 backing pump / PN24249
Drytel 1025 / D025AULPS710 Overview:
The Drytel series of products are dry pumping systems that include an Alcatel Adixen molecular drag pump (MDP) or a hybrid turbo pump (AMH) and an oil-free forepump. Designed to be used on a bench top or easily integrated into a system, these units provide a dry, clean vacuum from atmosphere to 10-8mbar (Torr).
With the Drytel 1025 series, Alcatel Adixen has a complete offer of tiny dry pumping groups for high vacuum applications.
The Drytel System Includes:
- Alcatel Adixen MDP5011 Turbo Drag Pump
- Alcatel Adixen AMD4 Diaphragm Dry Vacuum Pump
The two pumping stages working in series (MDP or AMH 020/AMD diaphragm pump) don’t require any lubricant to operate, permitting use on ultra-clean processes.
The Drytel series is the least expensive solution to achieve a clean vacuum down to 10-8mbar (Torr).
Unit is NEW and comes with a FULL 6-MONTH WARRANTY!
Drytel1025 Applications:
- Semiconductor
- Analytical Instrumentation
- Pharmaceutical
- Chemical
- Research and Development laboratories
- Backing of turbomolecular pumps
- Loadlock pumping
- Mass spectrometry
- Surface analysis
- Ion pump evacuation
- Cryopump regeneration
- Calibration
- Gas industry
- Gas lines
Adixen Drytel 1025 Dry Vacuum Turbo Pumping Station, AMD4 Dry Vacuum Pump with MDP5011, D025AULPS710
Adixen Drytel 1025 Technical Data:
- Pumping Speed (l/s):
- N2: 7.5
- He: 4
- H2: 3
- Ultimate Pressure (mbar) 10-6:
- Start-up Time (min): 2
- Cooling System: Air
- Maximum Ambient Temperature (°C): 0 to 40
- Maximum Power Consumption (VA): <160
- Standard Flange: 63 ISO-K
Adixen MDP 5011 Manual, Alcatel 5011, MDP 5011
Adixen Drytel 1025, Alcatel Drytel 1025, Drytel 1025 Pumping System, Drytel Turbo System
Get started with your repair:
We can have a repair estimate ready for your equipment within the hour of submission.
Start your equipment repair process by creating a Service RMA.
High quality service guaranteed
A&J Vacuum Services provides repairs on all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair and Mass Spectrometer repair. Our highly trained technicians will deliver the highest quality service and satisfaction.
We operate at our own full service repair facility which allows us to quickly and economically perform all repairs in a timely manner. Our advandced machinery enables us to handle all facets of the service and repair process. AJVS utilizes industry standard vibration analysis equipment and advanced testing equipment to troubleshoot and minimize all equipment failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
AJVS repair process:
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly of the pump, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and log pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
We can repair your:
- Turbo Pumps
- Rotary Vane Pumps
- Dry Vacuum Pumps
- Leak Detectors
- Scroll Dry Pumps
- Vacuum Boosters
- Diaphragm Dry Pumps
