- Dual-Stage, High Performance Rotary Vane Pump
- Three-Phase Motor w/Various Voltage Settings
- Integrated Temperature Sensor (3TF)
- Integrated Gas Ballast & Safety Valve
Shopping Cart ( )
Pfeiffer Duo 125 Vacuum Pump, Dual Stage, 3-Phase Motor, 3TF, 220/380 V 60 Hz, PKD47652 / PK D47 652
Condition:
Discontinued
Item#:PN01493
Mfr Part#:PKD47652 / PK D47 652
Manufacturer:Pfeiffer Vacuum
This product has been discontinued and is no longer available for sale
VIEW REPLACEMENT
Features:
Pfeiffer Duo 125 Vacuum Pump, Dual Stage, 3-Phase Motor, 3TF, 220/380 V 60 Hz, PKD47652 / PK D47 652
Pfeiffer Duo 125 Features:
- Dual-stage, High-performance Rotary Vane Pump Utilizing a Pumping Speed of 120 m^3/h; Includes a 3-Phase Motor
- Included temperature sensor (3TF) for Optimal Motor Protection & Durability
- Integrated Gas Ballast and HV Safety Valve
- Ideally Utilized for Low-to-Medium Intensity Vacuum Applications
- Special Feature: Various Motor Voltages for Worldwide Application & Unit Standardization
Duo 125 / PKD47652 Overview:
The Pfeiffer Duo 125 (3-Phase Motor) is a dual-stage rotary vane pump incorporating a pumping speed of 120 cubic meters per hour (m^3/h).
DuoLine rotary vane pumps are ideally suited to cover applications in the low-to-medium vacuum range with pressures of up to 20^(-3) mbar. Our DuoLine vacuum pumps offer reliable operation for critical industrial applications including drying processes, metallurgical processes, and resin potting and casting systems – serving either as a standalone pump or backing pump in our roots-pumping and turbo-pumping stations.
The use of a magnetic coupling minimizes maintenance requirements, contributing to considerable per-pump cost savings resulting from less-frequent maintenance intervals. The product likewise includes a temperature sensor (3TF) for enhanced protection.
A&J Vacuum services and repairs Pfeiffer Duo 125 Pumps along with all other Pfeiffer Rotary Vane and Turbo Pumps offered on our website. Please contact us for additional information about our service program or visit http://www.ajvs.com/service.php to access our Service page. We likewise offer emergency service and repair upon request. If you have any questions or would like to obtain additional information, please call A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
This item is non-returnable/non-refundable
Pfeiffer Duo 125 Vacuum Pump, Dual Stage, 3-Phase Motor, 3TF, 220/380 V 60 Hz, PKD47652 / PK D47 652
Pfeiffer Duo 125 Technical Data:
| Emission sound pressure level without gas ballast at 50 Hz | 75 dB (A) |
| Flange (in) | DN 63 ISO-F |
| Flange (out) | DN 63 ISO-F |
| Leak rate safety valve | 1 · 10-4 mbar l/s |
| Mains requirement: voltage (range) | 190-210/330-365 V (± 5 %) 50 Hz ; 200-230/360-400 V (± 5 %) 60 Hz |
| Operating fluid | P3 |
| Operating fluid filling | 13 l |
| Pumping speed at 50 Hz | 120 m3/h |
| Pumping speed at 60 Hz | 140 m3/h |
| Rated power 50 Hz | 4.0 kW |
| Rated power 60 Hz | 4.8 kW |
| Rotation speed at 50 Hz | 1000 rpm |
| Rotation speed at 60 Hz | 1200 rpm |
| Switch | No |
| Ultimate pressure with gas ballast | 6 · 10-3 mbar |
| Ultimate pressure without gas ballast | 3 · 10-3 mbar |
| Weight | 215 kg |
A&J Vacuum services and repairs Pfeiffer Duo 125 Pumps along with all other Pfeiffer Rotary Vane and Turbo Pumps offered on our website. Please contact us for additional information about our service program or visit http://www.ajvs.com/service.php to access our Service page. We likewise offer emergency service and repair upon request. If you have any questions or would like to obtain additional information, please call A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
