Edwards E2M1.5 Vacuum Pump, Dual Stage, Hydrocarbon Elite Z Oil, 200-230 VAC, IEC Connector, A37132919

Edwards E2M1.5 Vacuum Pump, Dual Stage, Hydrocarbon Elite Z Oil, 200-230 VAC, IEC Connector, A37132919

Edwards E2M1.5 Features:

• Pumping speeds of either 0.7 to 1.5 m3h‑1.
• Industry proven long term reliable performance.
• Free standing, compact design providing flexibility of use.
• Alternate side inlet connection port so that overall installation height can be reduced to minimum when required.
• Low noise, with the E2M0.7 at just 43 dB(A).
• Low energy consumption, with the E2M0.7 at 0.09 kW.
• O ring sealed sight glass allows visual inspection of oil level and condition.
• Gas ballast valve for large water vapour handling capacity.
• Simple installation and operation with no customer wiring.
• Forced air cooling ensures low pump surface temperature.
• Internal ATEX classification of Ex II 3 G c IIB T4.
• Approved EN61010, CSA22.2 and UL61010.

E2M1.5 / A37132919 Overview:

The Edwards Vacuum E2M 1.5 pumps are two-stage, direct drive, sliding vane pumps. The E2M1.5 pump is oil-sealed and designed for reliable, long-term operation. The pump is a free-standing unit. The drive is provided through a coupling by a single-phase motor.

The motor of this rotary vane vacuum pump is totally enclosed and is cooled by the motor-cooling fan which directs air along the motor fins. The motors are fitted with a thermal overload device. When the motor is too hot, the thermal overload device switches off the pump. The thermal overload device has an automatic reset; when the motor cools down, the device resets and the motor will restart.

An oil pressure system lubricates the pump shaft bearing surfaces and rotor sealing faces. The pump has an oil distribution valve which prevents discharge of oil to the pump interior (suckback) after the pump stops. The pumping chambers are air-tight, so this arrangement prevents oil suckback unless the gasballast valve is open.

You can inspect the level and condition of oil in the oil box reservoir through a sight-glass. An oil filler-plug is fitted to the top of the oil box. An oil drain-plug is fitted at the bottom of the oil box. The pump has a carrying handle, inlet-port, outlet nozzle and gas-ballast control. The pump is mounted on a steel baseplate on rubber pads.

E2M1.5 Applications:

• Analytical instruments
• Laboratory bench top vacuum
• Leak detectors, Helium
• Research and development
• Backing turbomolecular pumps

A&J Vacuum also repair / rebuild and service all Edwards E2M1.5, E2M2, E2M5, E2M8, E2M12 Series  Vacuum Pumps  along with all other Edwards  Turbo Pumps, Edwards Dry Pumps, Edwards Scroll Pumps and all other Edwards Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
