- Ultimate Pressure: 1 x 10-3 Torr.
- Outlet Flange NPT 2.00"
- Inlet Flange NPT 2.00"
- Peak Pumping Speed: 130 cfm
Shopping Cart ( )
Leybold / Oerlikon SV200 Single Stage Rotary Vane Pump, NPT 2" Inlet Flange & NPT 2" Outlet Flange
Condition:
Remanufactured
Call us for Availability
Item#:PN06686
Mfr Part#:
Manufacturer:Leybold
Price upon request
CONTACT US
Features:
Leybold / Oerlikon SV200 Single Stage Rotary Vane Pump, NPT 2" Inlet Flange & NPT 2" Outlet Flange
SV200 / Overview:
Fully refurbished Leybold / Oerlikon SV200 Single Stage Rotary Vane Pump coupled with a NPT 2" Inlet Flange and NPT 2" Outlet Flange. This Leybold / Oerlikon Rotary Vane Pump has a peak pumping velocity of 130 cfm and a final pressure of 1 x 10-3 Torr. It has been thoroughly examined and is ready for broad range of applications within the research and industrial industries. The Leybold / Oerlikon SV200 Pump comes with an entire 12-Month Warranty.
A rotary vane pump can be described as a positive-displacement pump that is comprised of vanes mounted to a rotor that rotates inside of an enclosure. In some instances these vanes can be of varying length and tensioned to maintain contact with the walls as the pump rotates.
The simplest rotary vane pump is a circular rotor revolving inside of a larger round enclosure. The centers of these two bands are offset, inducing eccentricity. Vanes are allowed to slide in and out of the rotor and seal on all edges, making vane chambers that do the pumping work. On the intake side of the pump, the vane chambers are increasing in volume. These increasing volume vane chambers are filled with fluid forced in by the inlet pressure. Inlet pressure level is actually the pressure level from the system being pumped, frequently just the atmosphere. On the exhaust side of the pump, the vane chambers are decreasing in volume, forcing fluid out of the pump. The activity of the vane drives out the same volume of fluid with each rotation. Multistage rotary vane vacuum pumps can reach pressures levels as low as 103 mbar (0.1 Pa).Visit the rotary vane pump wiki page for more information.
SV200 Applications:
- Gas analyzers
- Leak detection
- Mass spectrometers
- Other spectrometers
- Electron microscopes
- Surface analyzers
- Centrifuges
- Sterilization
- Electron tubes
- Lamps
- TV tubes (CRT)
- Refrigeration
- Air conditioning
- Drying
- Distillation
- Metallurgy
- Free drying
- CVD.LPCVD
- Ion implantation
- Dry etching
- Load-lock
- Cryogenics
- Gas recovery
- Oxygen pumping
A&J Vacuum Service / rebuild and repair all Leybold vacuum pumps. We service all versions of SV 100 vacuum pumps. AJVS also provides Customers with Leybold Scroll Pump service along with Vacuum Boosters, Leybold Vacuum Pumps, Leybold Helium Leak Detectors along with all other Leybold Turbo Pumping Stations, Leybold Turbo Pump Repair, Roots Pump Service and repair. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
This item is non-returnable/non-refundable
Leybold / Oerlikon SV200 Single Stage Rotary Vane Pump, NPT 2" Inlet Flange & NPT 2" Outlet Flange
Leybold SV200 Technical Data:
| Nominal speed (50Hz | 60Hz) | 180 m3/h (106 cfm) | 220 m3/h (129.5 cfm) |
| Pumping speed (50Hz | 60Hz) | 170 m3/h (100.1 cfm) | 200 m3/h (117.8 cfm) |
| Ultimate total pressure without gas ballast (50Hz | 60Hz) | ≤ 8 x 10-2 mbar (≤ 6 x 10-2 Torr) | ≤ 8 x 10-2 mbar (≤ 6 x 10-2 Torr) |
| Ultimate total pressure with gas ballast (50Hz | 60Hz) | ≤ 0.7 mbar (≤ 0.5 Torr) | ≤ 0.7 mbar (≤ 0.5 Torr) |
| Water vapor tolerance (50Hz | 60Hz) | With standard gas ballast - 30.0 mbar (22.5 Torr) With small gas ballast - ≤ 10.0 mbar (≤ 7.5 Torr) |
With standard gas ballast - 40.0 mbar (30.0 Torr) With small gas ballast - ≤ 50.0 mbar (≤ 37.5 Torr) |
| Water vapor capacity (50Hz | 60Hz) | With standard gas ballast - 3.4 kg/h (3.6 qt/hr) | With standard gas ballast - 5.4 kg/h (5.7 qt/hr) |
| Oil capacity (50Hz | 60Hz) | 5.0 l (5.3 qt) / 9.0 l (9.5 qt) | 5.0 l (5.3 qt) / 9.0 l (9.5 qt) |
| Noise level (50Hz | 60Hz) | 69 dB(A) | 73 dB(A) |
|
Admissible ambient temperature (50Hz | 60Hz) |
12 to 40 °C (54 to 104 °F) | 12 to 40 °C (54 to 104 °F) |
| Motor power (50Hz | 60Hz) | 4.0 kW (7.5 hp) | 4.6 kW (7.5 hp) |
| Nominal speed (50Hz | 60Hz) | 1450 min-1 (1450 rpm) | 1750 min-1 (1750 rpm) |
| Type of protection (50Hz | 60Hz) | IP 55-F | IP TEFC/55 |
| Materials in contact with the gas (50Hz | 60Hz) | Steel, cast iron, Aluminum, FPM (FKM), Glass, Polyamid 6.6, Filter material (Polymers, Paper), Epoxy resin & Glass fibre | Steel, cast iron, Aluminum, FPM (FKM), Glass, Polyamid 6.6, Filter material (Polymers, Paper), Epoxy resin & Glass fibre |
| Connections inside thread (50Hz | 60Hz) | Intake - 2" G or NPT Exhaust - 2" G or NPT |
Intake - 2" G or NPT Exhaust - 2" G or NPT |
| Weight with oil filling (50Hz | 60Hz) | 150 kg (331 lbs) | 160 kg (353 lbs) |
A&J Vacuum Service / rebuild and repair all Leybold vacuum pumps. We service all versions of SV 100 vacuum pumps. AJVS also provides Customers with Leybold Scroll Pump service along with Vacuum Boosters, Leybold Vacuum Pumps, Leybold Helium Leak Detectors along with all other Leybold Turbo Pumping Stations, Leybold Turbo Pump Repair, Roots Pump Service and repair. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
Item#:PN05858
Mfr Part#:Elite Z
Condition: In Stock
New
In Stock
$34.95
Item#:PN18188
Mfr Part#:L12000
Condition: Out of Stock
New
$28.50
Item#:PN18189
Mfr Part#:L12001
Condition: In Stock
New
In Stock
$68.60
Get started with your repair:
We can have a repair estimate ready for your equipment within the hour of submission.
Start your equipment repair process by creating a Service RMA.
High quality service guaranteed
A&J Vacuum Services provides repairs on all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair and Mass Spectrometer repair. Our highly trained technicians will deliver the highest quality service and satisfaction.
We operate at our own full service repair facility which allows us to quickly and economically perform all repairs in a timely manner. Our advandced machinery enables us to handle all facets of the service and repair process. AJVS utilizes industry standard vibration analysis equipment and advanced testing equipment to troubleshoot and minimize all equipment failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
AJVS repair process:
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly of the pump, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and log pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
