- Pumping Speed (50/60 Hz): 47 m3/h | 56 m3/h
- Ultimate Pressure w/ GB: < 1 x 10-1
- Water Vapor Tolerance: 10 mbar
- Noise Level: 57 dB(A)
Leybold SOGEVAC NEO D 40 Rotary Vane Pump, Three Phase, 180 - 264 / 342 - 506 V, 50/60 Hz, 970302V
Leybold SOGEVAC NEO D 40 Features:
- Clean and quiet
- Long-running performance
- No external exhaust filter required
- Rated pumping speed: 47 / 56 m3/h
- Noise level of 57 dB(A)
SOGEVAC NEO D 40 / 970302V Overview:
The SOGEVAC NEO D is designed for continuous operation at any inlet pressure and maintains the same robust industrial build as the rest of the SOGEVAC series. This latest generation of rotary vane vacuum pumps is well-suited for all dual-stage pumping applications.
The new SOGEVAC NEO D combines multiple advantages, but above all it stands out for being cleaner, quieter, and virtually maintenance-free. It is equipped with a high-quality exhaust filter integrated into the oil casing and is optimized for maximum uptime with long-life hydrocarbon oils.
SOGEVAC NEOD40 Applications:
- Analytics
- Glove boxes
- Sterilization
- R&D
- Heat treatment & plasma processes
A&J Vacuum Service / rebuild and repair all Leybold vacuum pumps. We service all versions of SOGEVAC NEO vacuum pumps. AJVS also provides Customers with Leybold Scroll Pump service along with Vacuum Boosters, Leybold Vacuum Pumps, Leybold Helium Leak Detectors along with all other Leybold Turbo Pumping Stations, Leybold Turbo Pump Repair, Roots Pump Service and repair. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
Leybold SOGEVAC NEO D 40 Rotary Vane Pump, Three Phase, 180 - 264 / 342 - 506 V, 50/60 Hz, 970302V
Leybold SOGEVAC NEO D 40 Technical Data:
- Frequency: 50/60 Hz
- Rated pumping speed: 47 m3/h | 56 m3/h
- Effective pumping speed: 40 m3/h | 48 m3/h
- Ultimate pressure without GB: < 8 x 10-3 mbar
- Ultimate pressure with GB: < 1 x 10-1 mbar
- Water vapor tolerance: 10 mbar
- Motor power -
- 3-phase motor: 1.15 kW | 1.5 kW
- 1-phase motor: 1.3 kW | 1.5 kW
- Frequency converter: 1.5 kW | 1.5 kW
- Noise level: 57 dB(A)
- Oil volume: 3 l
- Flanges: 40 KF
- Weight: 80 kg | 176 lb
- Dimensions L x W x H: 632 x 356 x 320 mm | 25 x 14 x 13 in
A&J Vacuum Service / rebuild and repair all Leybold vacuum pumps. We service all versions of SOGEVAC NEO vacuum pumps. AJVS also provides Customers with Leybold Scroll Pump service along with Vacuum Boosters, Leybold Vacuum Pumps, Leybold Helium Leak Detectors along with all other Leybold Turbo Pumping Stations, Leybold Turbo Pump Repair, Roots Pump Service and repair. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
Leybold SOGEVAC NEO D Brochure
|
Service and Repair - Turbo Pumps
- Rotary Vane Pumps
- Dry Vacuum Pumps
- Leak Detectors
- Scroll Dry Pumps
- Vacuum Boosters
- Diaphragm Dry Pumps
A & J Vacuum Services provides repair service for all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair, Mass Spectrometer repair, Rotary Vane Pump repair, Vacuum Booster repair, and Leak detector repair. Our highly trained technicians have years of experience and guarantee the highest quality service.
We operate at our own full service repair facility in Clifton, NJ. We have invested in state-of-the-art equipment including; complete line of decontamination, cleaning, drying, balancing, vibration analysis and software to minimize failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
We support all major manufacturers including Pfeiffer Vacuum, Alcatel / Adixen, Edwards Vacuum, Varian, Oerlikon / Leybod Vacuum, Vacuubrand, and Agilent Technologies.
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and long pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10-9 Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
Every pump and instrument is extensively tested for 48 hours. During our final tests, we monitor total pressure, temperature, vibration and noise level utilizing newest testing technologies and techniques specified by OEM. Upon request, we can provide our customers with a pump down graph. Call us for your free repair estimate at 1-973-249-0854.
