- Conductance at 1 · 10-2 16 l/s
- Filling quantity condensate max. 0.4 l
- Flange (in) DN 40 ISO-KF
- For pumping speed up to 65 m³/h | 38.26 cfm | 1,083.33 l/min
Shopping Cart ( )
Pfeiffer KLF 040, cold trap PKZ80008
Condition:
New
Item#:PN06085
Mfr Part#:PKZ80008
Manufacturer:Pfeiffer Vacuum
Features:
Pfeiffer KLF 040, cold trap PKZ80008
Pfeiffer KLF 040 Overview:
- The intake-side adsorption trap prevents oil backflow
- Cooling by means of liquid nitrogen, for example
- For inlet flange
- To be filled with liquid nitrogen or similar. Prevents backstreaming of any operating fluid by condensation
- Protects pump and operating fluid from harmful vapors from process
- Customer benefit: Longer life time of operating fluid and pump, clean vacuum
Pfeiffer Vacuum supplies a broad portfolio of mass spectrometers, ranging all the way to high-perfomance mass spectrometers for plasma analysis.
Pfeiffer Vacuum stands for innovative and custom vacuum solutions worldwide, for German engineering art, competent advice and reliable service. As the inventor of the turbopump, we have always been consistently setting standards in our industry and this claim to leadership will continue to drive us in the future.
Pfeiffer KLF 040 Dimensions:
A: ø 164 mm mm
B: 92 mm
C: ø 133 mm mm
D: 350 mm
E: 242 mm
F: 27 mm
A&J Vacuum Services offers full repair/service of Pfeiffer Pumps, along with all other brands offered on our website. AJVS also services Pfeiffer pumps. Please contact us for information about our service and repair program or click http://www.ajvs.com/service.php to access our services page. We also offer emergency service upon request. For more information, please email A&J Vacuum Services at info@ajvs.com or call (973) 249-0854. Thank you for choosing AJVS as your supplier.
This item is non-returnable/non-refundable
Pfeiffer KLF 040, cold trap PKZ80008
Pfeiffer KLF 040 Technical Data:
| Conductance at 1 · 10-2 | 16 l/s |
| Conductance at 100 hPa | 1000 l/s |
| Conductance at 1 hPa | 150 l/s |
| Filling quantity condensate max. | 0.4 l |
| Filling quantity coolant | 1.5 l |
| Flange (in) | DN 40 ISO-KF |
| Flange (out) | DN 40 ISO-KF |
| For pumping speed up to | 65 m³/h | 38.26 cfm | 1,083.33 l/min |
| Mounting orientation | 0° (HV flange top) |
| Weight | 6.5 kg | 14.33 lb |
A&J Vacuum Services offers full repair/service of Pfeiffer Pumps, along with all other brands offered on our website. AJVS also services Pfeiffer pumps. Please contact us for information about our service and repair program or click http://www.ajvs.com/service.php to access our services page. We also offer emergency service upon request. For more information, please email A&J Vacuum Services at info@ajvs.com or call (973) 249-0854. Thank you for choosing AJVS as your supplier.
