Pfeiffer Vacuum TPG 362 Single Gauge with 1 TPR 280 (CF-16), IKR 251 (CF40) and 3m Cables Pressure Measurement System

Main image
Image 1 Image 2 Image 3 Image 4
Condition: Discontinued
Item#:PN20824
Mfr Part#:
Manufacturer:Pfeiffer Vacuum
This product has been discontinued and is no longer available for sale
VIEW REPLACEMENT
Request a repair estimate Request sales quote Financing available
Discontinued Pfeiffer Vacuum TPG 362 Single Gauge with 1 TPR 280 (CF-16), IKR 251 (CF40) and 3m Cables Pressure Measurement System
Features:
  • Complete Measurement package
  • TPG 362 Digital Controller
  • TPR 280 CF 16, IKR 251 CF 40 Gauge Head
  • 2 - 3M Connecting Cable and 115V Mains Cables
  • Overview
  • Specifications
  • Manuals
  • Accessories
  • Service & Repair
12 months warranty

Pfeiffer Vacuum TPG 362 Single Gauge with 1 TPR 280 (CF-16), IKR 251 (CF40) and 3m Cables Pressure Measurement System



Included:


  • DualGaugeDisplay and control unit for two guages 100-250VAC, 50/60Hz, TPG 362, PT G28 290
  • Active Pirani transmitter TPR 280, CF 16, PT R26 951 A
  • ActiveCold Cathode Transmiter, IKR 251, CF 40, PT R25 502
  • 2 Gauige cables, length: 3 m



Pfeiffer Vacuum TPG 362 Single Gauge with 1 TPR 280 (CF-16), IKR 251 (CF40)  and 3m Cables Pressure Measurement System

Universal power supply for worldwide use.

*THERE ARE NO RETURNS ON THIS PRODUCT IF PRODUCT IS OPENED OR USED*

Pfeiffer Vacuum TPG 362 Single Gauge with 1 TPR 280 (CF-16), IKR 251 (CF40) and 3m Cables Pressure Measurement System



Technical Data TPG 362:

Ambient Temperature 5-50 °C | 41-122 °F | 278-323 K
Automatic Changeover: Pirani/Cold Cathode Configurable
Connection for Gauge 2
Display Rate ≥ 10 Hz
Error Signal: Working Contact, Potential-Free 1 Pcs.
Filter Time Constant, Rapid/Normal/Slow 0.02 s/0.15 s/0.75 s
I/O Interfaces USB, RS-485, Ethernet
Mains Requirement: Frequency (Range) 50/60 Hz
Mains Requirement: Power Consumption 65 VA
Mains Requirement: Voltage (Range) 100–240 V
Measurement Range 5 * 10^[-11] – 5.5 * 10^4 hPa
Measurement Rate ≥ 100 Hz
Measuring Channel 2 Pcs.
Power Consumption Max.. 65 VA
Protection Category IP20
Safety CE, UL
Set Point: Changeover Contact, Potential-Free 4 Pcs.
Set Point: Current AC 1 A
Set Point: Current DC 0.5 A
Set Point: Voltage AC 30 V AC
Set Point: Voltage DC 60 V DC
Set Point Number 4 Pcs.
Signal Output: Measuring Value, Analog 0 – 10 V
Temperature: Storage -20-60 °C | -4-140 °F | 253-333 K
Weight 1.1 kg | 2.43 lb



Technical Data TPR 280:

Accuracy: 1 * 10^(-3) to 100 hPa ± 15 %
Ambient Temperature 5-60 °C | 41-140 °F | 278-333 K
Bakeout Temperature at Flange 80 °C | 176 °F | 353 K
Feature Stainless Steel, Metal Sealed
Feedthrough Glass
Filament Tungsten
Flange Material Stainless Steel
Measurement Range 5 * 10^(-4) to 10^(3) hPa
Nominal Diameter DN 16 CF-R
Output Signal: Measurement Range 2.2–8.5 V
Output signal: Minimum Load 10 k
Maximum Pressure 10,000 hPa | 7,500 Torr | 10,000 mbar
Protection category IP40
Repeatability: 1 * 10^(-3) to 100 hPa ± 2 %
Resolution 1 % of reading
Response Time 80 ms
Seal Metal
Sensor Cable Length Min. 200 m
Supply: Power Consumption Max. 1 W
Supply: Voltage V DC 14 – 30 V DC
Storage Temperature -20-65 °C | -4-149 °F | 253-338 K
Volume 1.5 cm³
Weight 100 g



Technical Data IKR 251:

Inlet Flange: DN 40 CF-F
Maximum Measurement Range: 0.01 hPa
Minimum Measurement Range: 2 x 10-9 hPa
Output Signal: 1.8 to 8.5 V
Maximum Pressure: 1000 kPa
Supply Voltage: 15 to 30 V
Weight: 700 g / 1.5 lbs
