- Pumping Speed at 50 Hz: 59.0 m3 /h
- Pumping Speed at 60 Hz: 71.0 m3 /h
- Frequency: 50 / 60 Hz
- IP 55-F Motor Protection Rating
Shopping Cart ( )
Leybold Sogevac SV 65 B Euro W/O Gas Ballast Rotary Vane Vacuum Pump, 960402
Condition:
New
Item#:PN57632
Mfr Part#:960402
Manufacturer:Leybold
Features:
Leybold Sogevac SV 65 B Euro W/O Gas Ballast Rotary Vane Vacuum Pump, 960402
Leybold Sogevac SV 65 B Features:
- Small footprint, compact design
- Low noise level
- No external pipe
- No motor coupling up to SV65 B
- ATEX versions for categories 2 and 3, from SV40 B to SV100 B
Sogevac SV 65 B / 960402 Overview:
Oil-sealed rotary vane vacuum pumps are utilized across all fields of vacuum technology. They are well-suited for both industrial manufacturing and research applications. SOGEVAC pumps are used to produce rough and medium vacuum levels or serve as backing pumps in combination with Roots pumps or high vacuum pumps. These pumps are distinguished by their quiet operation and smooth performance.
The new SOGEVAC B pumps offer a compact design that minimizes spatial and design constraints for system integration. They are also compatible with most existing pump installations, requiring no special modifications for replacement.
Building on the reliable and user-friendly maintenance concept of the previous generation, the new SOGEVAC B pumps feature all service points accessible from the front. Improvements include a clearly positioned, angled oil sight glass visible from two directions, as well as a uniquely designed system for easier replacement of the exhaust demister. These enhancements make the new SOGEVAC B pumps exceptionally well-suited for a wide range of rough vacuum applications.
Sogevac SV65B Applications:
- Vacuum packaging (chamber machines, table top machines, modified atmosphere, rollstock…)
- Vacuum processing (cutting, blending, marinating, tumbling, stuffing…)
- Central vacuum systems
- Degassing
- Drying / Filling
- Freeze Drying
- Impregnation
- Leak testing
- Laser
- Handling / Lifting
A&J Vacuum services and repairs Leybold Scroll Vacuum Pumps, Leybold Turbo Pump repair, Leybold Rotary Vane Pumps along with all other Pumps available on our website. Please contact us for additional information concerning our service program or click http://www.ajvs.com/service.php to access our Services page. We likewise offer emergency service and repair upon request. For more information, please contact A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
This item is non-returnable/non-refundable
Leybold Sogevac SV 65 B Euro W/O Gas Ballast Rotary Vane Vacuum Pump, 960402
Leybold Sogevac SV 65 B Technical Data:
| Frequency | 50 / 60 Hz |
| Noise level | 60/64 dB(A) |
| Oil volume | 2.0 l |
| Operating fluid | LEYBONOL LVO 120 |
| Rated pumping speed | 39 / 47 m3/h |
| Ultimate pressure with gas ballast | < 1.5 mbar |
| Ultimate pressure without gas ballast | < 0.5 mbar |
| Water vapor tolerance | 30 mbar |
| Inlet connection | G 1 1/4" Inside thread |
| Outlet connection | G 1 1/4" Inside thread |
| Nominal pumping speed at 50 Hz | 59.0 m3 /h | 34.8 cfm |
| Nominal pumping speed at 60 Hz | 71.0 m3 /h | 41.8 cfm |
| Pumping speed at 50 Hz | 54.0 m3 /h | 31.8 cfm |
| Pumping speed at 60 Hz | 64.0 m3 /h | 37.7 cfm |
| Noise level to DIN 45 635 without gas ballast | 60 - 64 dB(A) |
| Mains connection | 3-ph, 230/400 V, 50 Hz 3-ph, 460 V, 60 Hz |
| Motor rating at 50 Hz | 1.5 kW | 2.0 HP |
| Motor rating at 60 Hz | 1.8 kW | 2.4 HP |
| Rotation speed at 50 Hz | 1.500 min-1 | 1.500 rpm |
| Rotation speed at 60 Hz | 1.800 min-1 | 1.800 rpm |
| Motor protection rating | IP 55-F |
| Admissible ambient temperature | +12 to +40°C | +54 to +104°F |
| Weight | 49 kg | 108 lbs |
A&J Vacuum services and repairs Leybold Scroll Vacuum Pumps, Leybold Turbo Pump repair, Leybold Rotary Vane Pumps along with all other Pumps available on our website. Please contact us for additional information concerning our service program or click http://www.ajvs.com/service.php to access our Services page. We likewise offer emergency service and repair upon request. For more information, please contact A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
