- Inlet Flange: DN 100 ISO-K
- Outlet Flange: DN 16 ISO-KF / G 1/4"
- Fully Rebuilt
- P/N PMP03900
Shopping Cart ( )
Pfeiffer Vacuum HiPace 300 Turbo Pump with TC 400 Controller, PM P05 424 / PMP05424
Condition:
Remanufactured
In Stock
Item#:PN57605
Mfr Part#:PM P05 424 / PMP05424
Manufacturer:Pfeiffer Vacuum
Price upon request
CONTACT US
Features:
Pfeiffer Vacuum HiPace 300 Turbo Pump with TC 400 Controller, PM P05 424 / PMP05424
Pfeiffer HiPace 300 Features:
- Rugged, powerful turbopump with a pumping speed of up to 260 l/s for N2
- Integrated TC 400 drive electronics
- Inlet Flange: DN 100 ISO-K
- Ideal for analytical and industrial applications
- For installation in any orientation
- With integrated water cooling for maximum gas throughput
- Flexible through the ability to employ up to 4 accessories
- Ideal for fast cycles
- Extensive accessories expand the range of applications
- Cooling fan included
Pfeiffer HiPace 300 Overview:
The Pfeiffer HiPace 300 PM P03 900 DN 100 ISO-K is a complete line of compact yet powerful turbo pump featuring pumping speeds that range from 10 - 2,000 liters per second. These models are cost-effective and offer flexible installation in any orientation.
The Pfeiffer Hipace 300 Turbo Vacuum Pump's proven bearing system provides unrivaled dependability and their sophisticated rotor design makes for higher pumping speeds, higher backing pump compatibility, higher gas throughputs and good compression for light gasses.
The turbopump HiPace 300 forms a complete unit together with the electronic drive unit TC 400. This turbopump offers water as well as air cooling. This pump has not integrated power supply.
Cooling fan included.
Pfeiffer HiPace300 Scope of Delivery:
- Turbopump with electronic drive unit
- Mating plug for the connection "remote" on the TC 400 (type dependent)
- Mating plug for the connection "E74" on the TC 400 (type dependent)
- Protective cover for the high vacuum flange and the fore-vacuum flange
- Operating instructions
Pfeiffer HiPace300 Applications:
- Analytical applications
- Illuminant Industry
- Optical / glass Industry
- Research facilities
- Semiconductor Industry
- Vacuum coating technology
- Vacuum metallurgy
- Vacuum leak detection technology
- Sciex instrument pump
A&J Vacuum Repair / Rebuild and Service all Pfeiffer Vacuum Hipace 300 Turbo Pumps along with all other Pfeiffer Turbo Pump Service and repair. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
Pfeiffer Vacuum HiPace 300 Turbo Pump with TC 400 Controller, PM P05 424 / PMP05424
Pfeiffer HiPace 300 Technical Data:
| Bearing | Hybrid |
| Compression ratio for Ar | > 1 · 1011 |
| Compression ratio for H2 | 9 · 105 |
| Compression ratio for He | > 1 · 108 |
| Compression ratio for N2 | > 1 · 1011 |
| Cooling method, optional | Air |
| Cooling method, standard | Water |
| Cooling water flow | 50 l/h |
| Cooling water flow, max | 50 l/h |
| Cooling water flow, min | 50 l/h |
| Cooling water temperature | 15-35 °C | 59-95 °F | 288-308 K |
| Current max. | 12,5 A |
| Electronic drive unit | with TC 400 |
| Flange (in) | DN 100 ISO-K |
| Flange (out) | DN 16 ISO-KF/G ¼" |
| Fore-vacuum max. for N2 | 20 hPa | 15 Torr | 20 mbar |
| Gas throughput at full rotational speed for Ar | 7 hPa·l/s |
| Gas throughput at full rotational speed for H2 | > 14 hPa·l/s |
| Gas throughput at full rotational speed for He | 20 hPa·l/s |
| Gas throughput at full rotational speed for N2 | 14 hPa·l/s |
| I/O interfaces | RS-485, Remote |
| Interface, extended | Profibus, DeviceNet, E74 |
| Mounting orientation | Any |
| Permissible magnetic field max. | 5.5 mT |
| Power consumption max. | 300 W |
| Protection category | IP54 |
| Pumping speed for Ar | 255 l/s |
| Pumping speed for H2 | 220 l/s |
| Pumping speed for He | 255 l/s |
| Pumping speed for N2 | 260 l/s |
| Rotation speed ± 2 % | 60,000 rpm | 60,000 min-1 |
| Rotation speed variable | 35 – 100 % |
| Run-up time | 1.8 min |
| Sound pressure level | ≤50 dB(A) |
| Ultimate pressure | 1 · 10-7 hPa | 7.5 · 10-8 Torr | 1 · 10-7 mbar |
| Ultimate pressure without gas ballast | 1 · 10-7 hPa | 7.5 · 10-8 Torr | 1 · 10-7 mbar |
| Venting connection | G 1/8" |
| Weight | 6.7 kg | 14.77 lb |
A&J Vacuum Repair / Rebuild and Service all Pfeiffer Vacuum Hipace 300 Turbo Pumps along with all other Pfeiffer Turbo Pump Service and repair. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
