- Pumping speed: for N2 500 l/s,
- Ultimate pressure < 1x10-10 mbar
- Air or Water Cooling available
Shopping Cart ( )
Pfeiffer Vacuum TPH 510 Turbo Pump, Bottom Flange, DN-160 ISO, PMP01182 / PM P01 182
Condition:
Remanufactured
Call us for Availability
Item#:PN07842
Mfr Part#:PMP01182 / PM P01 182
Manufacturer:Pfeiffer Vacuum
Price upon request
CONTACT US
Features:
Pfeiffer Vacuum TPH 510 Turbo Pump, Bottom Flange, DN-160 ISO, PMP01182 / PM P01 182
TPH 510 / PMP01182 Overview:
This Pfeiffer TPH 510 Turbo Pump has two ceramic bearings at each end to support rotor. The Turbo Pumps TPU 510 and TPH510 PMP01182 models are identical in terms of design.
Pump has a free of wear permanent magnetic bearing at high vacuum side and oil lubricated ceramic bearing at the backing side. The Turbo Pumps TMH and TMU models are identical in terms of design. They only differ in their intake flange. The pumps have a free of wear permanent magnetic bearing at high vacuum side and oil lubricated ceramic bearing at the backing side. Turbo pump designed for a wide range of applications in research industry.
This Pfeiffer TPH-510 Turbo Pump is lubricated with Pfeiffer TL 011 Turbo Pump fluid PM006034 AT / PN07244
Pfeiffer TPH 510 and TPU 510 only differ in their intake flange. TPH 510 comes with DN 160 ISO-K Inlet Flange, and TPU510 comes with DN-160 CF-F Conflat Inlet Flange.
Pfeiffer TPH 510 can have three different Inlet Flange orientations.
- TPH-510 Top Flange
- TPH-510 Side Flange
- TPH-510 Bottom Flange
Pfieffer 510 Turbo Pump can be operated with one of the following Electronic Turbo Pump Controllers.
- Pfeiffer TCP 121 / PMC01475 / PN06831
- Pfeiffer TCP 300 / PMC01259 / PN00341
- Pfeiffer TCP 310 / PMC01520 / PN06829
- Pfeiffer TCP 380 / PMC01490 / PN06827
Those Pfeiffer Vacuum Turbo Pump Controllers are well design to be integrated into your High Vacuum System Vacuum, and can be rack mounted for easy panel access.
Pump is fully rebuilt and tested and comes with full 12-MONTHS WARRANTY !
This Pump is fully rebuilt and comes with FULL 12-MONTHS WARRANTY!
TPH510 Applications:
- Freeze drying - packaging industry
- Degassing, casting, dry vacuum smelting (super-pure metals)
- Incandescent lamp manufacturing
- Electronic tubes
- Thin film deposition
- Space simulation
- Cryogenic research
- Electron microscopy
- Nuclear physics, Plasma physics, High energy physics
- Particle accelerators - Storage rings
A&J Vacuum also repair / rebuild and service Pfeiffer TPH 510 / PM P01 182 Turbo Pumps along with all other Pfeiffer Vacuum pumps and Pfeiffer Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
This item is non-returnable/non-refundable
Pfeiffer Vacuum TPH 510 Turbo Pump, Bottom Flange, DN-160 ISO, PMP01182 / PM P01 182
Pfeiffer TPH 510 Technical Data:
| Intake flange | DN 160 ISO-K |
| Fore-vacuum flange | DN 40 KF |
| Volume flow rate | |
| N2 | 500 l/s |
| He | 570 l/s |
| H2 | 500 l/s |
| Recommended backing pump | 12 m3/h |
| Electronic drive unit | TCP 300 / 310 / 380 |
| Compression ratio | |
| N2 | 8 x 109 |
| He | 1.5 x 104 |
| H2 | 1 x 103 |
| Ultimate pressure | 10-11 mbar |
| Ultimate operating pressure | < 1 x 10-10 |
| Speed | 60,000 rpm |
| Start-up time w/ TCP 300 / 310 | 6 min |
| Permissable magnetic field | 6 mT |
| Oil filling | 2 x 10 cm3 |
| Cooling water requirement | 15 l/h |
| Cooling water temperature | 5 - 25°C |
| Permissable ambient temperature for air cooling | 0 - 35°C |
| Weight | 28 kg |
A&J Vacuum also repair / rebuild and service Pfeiffer TPH 510 / PM P01 182 Turbo Pumps along with all other Pfeiffer Vacuum pumps and Pfeiffer Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
Pfeiffer Vacuum TPH 510 Turbomolecular Pump, Pfeiffer Balzers TPH 510 Turbo Pump
Item#:PN06826
Mfr Part#:PM128010-T
Condition: Ships Within 1-3 Days
Discontinued
$695.25
Item#:PN06130
Mfr Part#:2000020389 / PM 011 232 -X / PM011232-X
Condition: In Stock
Remanufactured
In Stock
$650.00
Item#:PN06829
Mfr Part#:PMC01520 / PM C01 520
Condition: In Stock
Remanufactured
In Stock
$1,799.00
Item#:PN07224
Mfr Part#:PM 414 095-X / PM 414 095-X
Condition: In Stock
Demo
In Stock
$225.00
Item#:PN17846
Mfr Part#:PN17846
Condition: In Stock
Remanufactured
In Stock
$64.00
Get started with your repair:
We can have a repair estimate ready for your equipment within the hour of submission.
Start your equipment repair process by creating a Service RMA.
High quality service guaranteed
A&J Vacuum Services provides repairs on all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair and Mass Spectrometer repair. Our highly trained technicians will deliver the highest quality service and satisfaction.
We operate at our own full service repair facility which allows us to quickly and economically perform all repairs in a timely manner. Our advandced machinery enables us to handle all facets of the service and repair process. AJVS utilizes industry standard vibration analysis equipment and advanced testing equipment to troubleshoot and minimize all equipment failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
AJVS repair process:
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly of the pump, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and log pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
