- Fully Remanufactured
- Pumping speed: for N2 550 l/s,
- P/N 9699050
- CF-160 inlet Flange
Shopping Cart ( )
Agilent Technologies / Varian V 550 Turbo Pump, DN-160 CF, 969-9050
Condition:
Remanufactured
Call us for Availability
Item#:PN15769
Mfr Part#:9699050
Manufacturer:Agilent Technologies / Varian
Price upon request
CONTACT US
Features:
Fully Refurbished Agilent Technologies / Varian TV550 Turbo Vacuum Pump, DN 160 CF, 969-9050
Varian V550 Overview:
The Turbo-V550 pump consists of a high frequency motor driving a turbine fitted with 8 bladed stages and 4 Macrotorr stages. The turbine rotates in an anticlockwise direction when viewed from the high vacuum flange end.
The turbine is made of high-strength, light aluminium alloy, and is machined from a single block of aluminium. The turbine blades have six different angles, from 40° to 16°, while the Macrotorr stages are in form of discs
The turbine rotor is supported by permanently lubricated high precision ceramic ball bearings installed on the forevacuum side of the pump.
The static blades of the stator are made of stainless steel. These are supported and accurately positioned by spacer rings.
The Macrotorr stators are in the form of selfpositioning machined discs with pumping channels and an opening restricted by the corresponding rotor discs. These are made of aluminium alloy.
During normal operation, the motor is fed with a voltage of 56 Vac three-phase at 700 Hz. To reduce losses during start-up to a minimum, the frequency increases according to a ramp with a higher initial voltage/frequency ratio.
The external body of the pump is shaped so that the pump can function with natural convection air cooling. Kits are available for water cooling or forced air cooling to cool the pump in the cases where it is used under heavy load or when natural convection is insufficient for cooling purposes.
Varian V550 Compression Ratio:
Varian V550 Dimensions:
Click Here for Varian V550 Manual
A&J Vacuum also repair / rebuild and service Varian V550 / 9699049 Turbo Pumps V-550 and Turbo Pump Controllers along with all other Varian and Agilent Technology Vacuum Rotary Vane Pumps, Varian Dry Scroll Pump repair, Varian Leak Detector Repair and all other Pfeiffer Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854
This item is non-returnable/non-refundable
Fully Refurbished Agilent Technologies / Varian TV550 Turbo Vacuum Pump, DN 160 CF, 969-9050
Varian V550 Technical Data:
Click Here for Varian V550 Manual
A&J Vacuum also repair / rebuild and service Varian V550 / 9699049 Turbo Pumps V-550 and Turbo Pump Controllers along with all other Varian and Agilent Technology Vacuum Rotary Vane Pumps, Varian Dry Scroll Pump repair, Varian Leak Detector Repair and all other Pfeiffer Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854
AJVS_Vacuum_Pump_Turbo_Pump_Service_and_Repair.pdf
AJVS_Varian_V_550_Turbo_Pump_Sales_and_Repair.pdf
Item#:PN15894
Mfr Part#:9699347
Condition: Out of Stock
New
$204.00
Item#:PN15890
Mfr Part#:969-9302
Condition: In Stock
New
In Stock
$132.00
Get started with your repair:
We can have a repair estimate ready for your equipment within the hour of submission.
Start your equipment repair process by creating a Service RMA.
High quality service guaranteed
A&J Vacuum Services provides repairs on all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair and Mass Spectrometer repair. Our highly trained technicians will deliver the highest quality service and satisfaction.
We operate at our own full service repair facility which allows us to quickly and economically perform all repairs in a timely manner. Our advandced machinery enables us to handle all facets of the service and repair process. AJVS utilizes industry standard vibration analysis equipment and advanced testing equipment to troubleshoot and minimize all equipment failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
AJVS repair process:
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly of the pump, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and log pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
We can repair your:
- Turbo Pumps
- Rotary Vane Pumps
- Dry Vacuum Pumps
- Leak Detectors
- Scroll Dry Pumps
- Vacuum Boosters
- Diaphragm Dry Pumps
