- Dual-Stage High Performance Rotary Vane Pump
- Integrated Gas Ballast & Safety Valve
- Includes Option For Magnetic Coupling
- Maximum Exhaust Pressure 1500 hPa
Shopping Cart ( )
Pfeiffer DUO 3, Rotary Vane Pump, 24 VDC, Lubrication, Inland 45, DN 16 ISO-KF, PK D57 563 D / PKD57563D
Condition:
Discontinued
Item#:PN22936
Mfr Part#:PK D57 563 D / PKD57563D
Manufacturer:Pfeiffer Vacuum
This product has been discontinued and is no longer available for sale
VIEW REPLACEMENT
Features:
Pfeiffer DUO 3, Rotary Vane Pump, 24 VDC, Lubrication, Inland 45, DN 16 ISO-KF, PK D57 563 D / PKD57563D
Power cable is not included. Please view the accessories tab for compatible cables.
Pfeiffer DUO 3 Features:
- Pumping speed of 2.5 m³/h
- Dual stage, high performance rotary vane pump
- Magnetically coupled
- OME oil return device included
- Low noise level
- Low maintenance due to optional magnetic coupling and brushless drive
DUO 3 / PKD57563D Overview:
The Pfeiffer DUO 3 Vacuum Pump is a direct replacement for the now-obsolete Pfeiffer DUO 2.5 Vacuum Pump. The Pfeiffer DUO 3 Vacuum Pump series includes oil-sealed, two-stage Rotary Vane Vacuum Pumps.
The Pfeiffer DUO 3 vacuum pumps are equipped with a high vacuum safety valve, which, when the pump is at a standstill, tightly closes the vacuum chamber while simultaneously allowing for ventillation of the pump.
Dimensions:
A&J Vacuum services and repairs Pfeiffer DUO 3, DUO 3M, along with all other Pfeiffer Vacuum and Turbo Pumps available on our website. Please contact us for additional information concerning our service program or click http://www.ajvs.com/service.php to access our Services page. We likewise offer emergency service and repair upon request. For more information, please contact A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
This item is non-returnable/non-refundable
Pfeiffer DUO 3, Rotary Vane Pump, 24 VDC, Lubrication, Inland 45, DN 16 ISO-KF, PK D57 563 D / PKD57563D
Power cable is not included. Please view the accessories tab for compatible cables.
Pfeiffer DUO 3 Technical Data:
| Ambient temperature | 20 – 40 °C | 68 – 104 °F | 293.15 – 313.15 K |
| Certification | CE |
| Connection flange (in) | DN 16 ISO-KF |
| Connection flange (out) | DN 16 ISO-KF |
| Cooling method | Air (Forced convection) |
| Current, max. | 16 A |
| Dimensions (L x W x H) | 313 x 123 x 173 mm | 12.32 x 4.84 x 6.81 inch |
| Exhaust pressure, max. | 1500 hPa | 1,125 Torr | 1,500 mbar |
| Exhaust pressure, min. | 250 hPa | 187.5 Torr | 250 mbar |
| Input voltage(s) | 24 V DC (±10 %) |
| Leakage rate safety valve | 1 · 10-5 Pa m³/s | 7.5 · 10-5 Torr l/s | 1 · 10-4 mbar l/s |
| Mains cable | Yes |
| Motor type | DC motor |
| Number of pumping stages | Two stage |
| Operating fluid | Inland 45 |
| Power consumption max. | 340 W |
| Protection degree | IP20 |
| Pumping principle | Oil-lubricated |
| Pumping speed | 2.5 m³/h | 1.47 cfm | 41.67 l/min |
| Recommended on-site electric fuse protection | 16 A |
| Rotation speed | ≥ 3000 rpm |
| Ultimate pressure | 3 · 10-3 hPa | 2.25 · 10-3 Torr | 3 · 10-3 mbar |
| Ultimate pressure with gas ballast | 3 · 10-3 hPa | 2.25 · 10-3 Torr | 3 · 10-3 mbar |
| Weight approx. | 8.5 kg | 18.74 lb |
A&J Vacuum services and repairs Pfeiffer DUO 3, DUO 3M, along with all other Pfeiffer Vacuum and Turbo Pumps available on our website. Please contact us for additional information concerning our service program or click http://www.ajvs.com/service.php to access our Services page. We likewise offer emergency service and repair upon request. For more information, please contact A&J Vacuum Services at (973) 249-0854. Thank you for choosing AJVS as your supplier.
