Pfeiffer HiCube 350 Neo Mobile Turbo Pumping Station, Includes HiPace 350 Turbo Pump (DN 100 ISO-K), Hiscroll 18 Dry Scroll Pump and 7" Touch Screen Controller, PM Q240 320 00 / PMQ24032000

Pfeiffer HiCube 350 Neo Mobile Turbo Pumping Station, Includes HiPace 350 Turbo Pump (DN 100 ISO-K), Hiscroll 18 Dry Scroll Pump and 7" Touch Screen Controller, PM Q240 320 00 / PMQ24032000

Pfeiffer HiCube Neo 350 Mobile Features:

• The HiCube Neo Compact series of pumping stations for all high vacuum applications
• Air-cooled and ready for operation with HiPace 350 Neo Turbo Pump and HiScroll 18  Dry Scroll Backing Pump
• Remote Control possible via web server
• Pfeiffer HiCube 80 Neo / comes with DN 100 ISO-K inlet flange / PM P07 040 140
• Pfeiffer Hiscroll 18 / DN 25 KF / PD S30 000
• It is controlled intuitively via the 7“ color touch screen control panel
• Pfieffer HiCube Neo Mobile voltage requirement 90-132 V AC, 50/60 Hz; 185-265 V AC, 50/60 Hz
• The HiCube Neo is ready for immediate use thanks to its plugand-play operation
• Reliable and robust​

HiCube Neo 350 Mobile / PMQ24032000 Overview:

Powerful and versatile With a pumping speed of 80–800 l/s, our HiCube Neo turbo pumping unit offers the performance you need for your high vacuum applications. When using a HiPace H, an ultra-high vacuum of <10-10 hPa can be achieved. The availability of different backing pumps, such as diaphragm, rotary vane, scroll and multi-stage Roots pumps, makes it extremely versatile. With desktop and standalone versions and configurability for any application, we offer maximum flexibility

The dashboard appears automatically when you switch on the HiCube Neo pumping station. Hicube Neo dashboard provides information about the operating status of the connected pump, the system status, the pressure (if the gauge is connected), the status of the components in operation/during shutdown, the parameter list, and the actual rotation speed.

Intuitive control and analysis The HiCube Neo is ready for immediate use thanks to its plugand-play operation. It is controlled intuitively via the 7“ color touch screen control panel. Convenient monitoring and remote control via the web server are also possible, while the recording of measurement data via OPC UA, enables detailed analysis for optimum process control. Combine the HiCube Neo with our comprehensive portfolio of measuring devices and other accessories to create customized solutions for any high vacuum application.

The Pfeiffer Vacuum HiCube 350 Neo Mobile Turbo Pumping Station is the trully portable and bench top pumping unit for many of the High Vacuum Applications. DN-100 ISO-K Inlet Flange makes this system trully High Vacuum Pumping System.

The Hicube 350 Neo Station has a modern design with the latest turbo pump and electronics technology. Fully integrated Pfeiffer Hiscroll 18 Dry Diaphragm Pump provides positive displacement with a periodic change of size of the suction chamber produced by the movement of the diaphragm. The gas flow causes the valves to open and close automatically. The pump units are directly connected to the drive motor.

What’s so special about the HiCube NEO Mobile Turbo Systems: The combination of a turbopump from the HiPace Neo series Turbo Pump and a backing pump designed for the user’s specific application needs. HiCube Neo Mobile offers several different configuarations listed below available uppon request.

The HiCube Neo turbo pumping station is distinguished by its modular construction. Thanks to the many possibilities of combining different turbopumps and backing pumps, the HiCube Neo can be configured to meet the requirements of all applications in high and ultra-high vacuums. In addition, all HiCube Neo Turbo Stations feature connectivity for digital pressure gauges.

All HiCube Neo turbo pumping stations are fitted with particularly energy-efficient backing pumps that have a DC drive. The turbopump and the backing pump form a single unit in the pumping station. If there is no gas load in the vacuum, the pumping station automatically reduces the backing pump output. This results in maximum energy savings.

HiCube350NeoMobile Applications:

• Gas analysis
• Calibration of measuring tubes
• Laboratory applications
• Research, Development and Scientific
• Particle accelerators
• Residual gas analysis
• Cryogenics​

A&J Vacuum also repair / rebuild and service all Pfeiffer HiCube 350 Neo / Eco Pumping Stations along with all other Pfeiffer Vacuum MVP Diaphragm Pumps, Rotary Vane Pumps, Pfeiffer Dry Pumps, Pfeiffer Leak Detector Repair and all other Pfeiffer Vacuum Rotary Vane pumps. We also service New Leybold Turbo Pumping Stations, New Edwards turbo Pump Stations. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
