- Vacuum connection: DN 16 ISO-KF
- Measurement range: Atmosphere to 1e-4 mbar
- Standard Filament
- 2 Set Point
Leybold TTR 96 RNS Thermovac Vacuum Gauge, DN 16 ISO-KF, Leybold Standard Output, FC68/RJ45, 21L2211100
This model replaces TTR 96 P/N 230045
Leybold TTR 91RN Thermovac Overview:
The THERMOVAC Transmitters are active sensors using the unique MEMS-Pirani technology (Micro-Electro-Mechanical-Systems) They offer analog voltage output and the S-versions offer set point relays for improved process control For chemical and aggressive applications, the C-versions are equipped with a Parylene HT®- coated sensor The THERMOVAC series is also equipped with a LED-ring (360°) showing the status of the sensor The TTR91RN and 916 N have a touch display and/or digital interfaces available.
Leybold TTR91RN Technology
Operation of the THERMOVAC transmitters is based on the thermal conductivity principle after Pirani. Different versions offer set point relays for improved process control. The THERMOVAC series is equipped with a LED-ring (360°) showing the sensor status. Benefits
- New MEMS-Pirani for high resistance
- Fast response and high accuracy: time saving and highly reliable
- Optimized price-to-performance ratio
Leybold TTR 91 RN Sensor Technology
The THERMOVAC transmitters measurement principle is based on thermal conductivity The transmitters are equipped with a MEMS-Pirani sensing cell that consists of a silicon chip with a heated resistive element The THERMOVAC transmitters with the coated MEMS-Pirani are well suited for harsh processes and therefore more robust than the uncoated versions Built-in relays allow switching functions to be performed directly by the transmitter, without the need of a programmable control An integration of the transmitters in programmable control systems is facilitated by the linear characteristic, which can be defined by entering a simple equation into a PLC or computer
Typical Leybold TTR 91RN applications
The THERMOVAC Transmitters offer a high degree of versatility They are suited for applications in the medium and rough vacuum range
Typical applications are:
- Analytical instrumentation
- Research and development
- Vacuum Drying
- Controlling of ionization gauges
- Activation of UHV gauges
- System process control
- Process industry
- Coated versions for improved chemical resistance
- General foreline vacuum measurement
