Edwards RV 5 Vacuum Pump (Maintenance Kit) Major Overhaul Rebuild, Repair Kit (RV5 Major Kit), A65201131RV5
Condition:
New
In Stock
Item#:PN01520
Mfr Part#:65201131RV5
Manufacturer:Edwards Vacuum
Features:
Edwards RV 5 Vacuum Pump (Maintenance Kit) Major Overhaul Rebuild, Repair Kit (RV5 Major Kit), A65201131RV5
Overview:
The Edwards RV5 Major Overhaul Kit includes everything needed for major overhauls on the Edwards RV5 Rotary Vane Vacuum Pump.
We also do minor and major repairs for all Edwards Rotary Vane Vacuum Pumps.
A&J Vacuum Repair / Rebuild and Rervice all Edwards RV3, RV5, RV8, RV12, E2M2, E2M5, E2M8, E2M12 Series Vacuum Pumps along with all other Edwards Turbo Pumps, Edwards Dry Pumps, Edwards Scroll Pumps and all other Edwards Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854
Edwards RV 5 Vacuum Pump (Maintenance Kit) Major Overhaul Rebuild, Repair Kit (RV5 Major Kit), A65201131RV5
Edwards RV5 Major Overhaul Kit contains the following parts:
| DESCRIPTION | PART NO. | QTY |
| Air Bleed Assembly | 65201005 | 1 |
| Viton Shaft Seal (Inner) | E02109066 | 1 |
| Viton Shaft Seal (Outer) | E02109124 | 1 |
| Shaft Seal Spacer | E02109125 | 1 |
| O-Ring | E02120036 | 1 |
| O-Ring | E02120037 | 1 |
| O-Ring | E02120077 | 1 |
| O-Ring | E02122031 | 1 |
| O-Ring | E02122055 | 1 |
| O-Ring | E02125026 | 3 |
| Oil Pump Vane | E20402500G | 1 |
| 1st Stage Vane | E20402526G | 2 |
| 2nd Stage Vane | E20402529G | 2 |
| Spring (Dump&Check) | E20525047 | 2 |
| Spring (G/B Control) | E20525048 | 1 |
| Spring (C/B Control) | E20525049 | 1 |
| Coupling Element | E21071077 | 1 |
| O-Ring | E23712039 | 1 |
| O-Ring | E23724070 | 1 |
| O-Ring | E23724071 | 1 |
| O-Ring | E23724072 | 1 |
| O-Ring | E23724073 | 3 |
| Exhaust Diaphragm | E25908123 | 1 |
| Coupling | E25908127 | 1 |
| Oil Pressure Valve | E25908129 | 1 |
| Dump Valve | E25908226 | 1 |
| G/B Check Valve | E26501036 | 1 |
| U-Seal | E26501040 | 1 |
| Mounting Foot | E26501041 | 4 |
| Shouldered Washer | E27154018 | 1 |
| Gasket (Oil Box) | E27160005 | 1 |
| Gasket (Cartridge) | E27160006 | 1 |
| Gasket (Top Plate) | E27160007 | 1 |
| Gasket (Seal) | E27160008 | 1 |
| Motor Gasket | E65201019 | 1 |
| Reed Valve | E65201029 | 1 |
| Valve Pad | E70000557 | 1 |
A&J Vacuum Repair / Rebuild and Rervice all Edwards RV3, RV5, RV8, RV12, E2M2, E2M5, E2M8, E2M12 Series Vacuum Pumps along with all other Edwards Turbo Pumps, Edwards Dry Pumps, Edwards Scroll Pumps and all other Edwards Vacuum Rotary Vane pumps. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854
Edwards RV Series Service Instructions with parts diagrams A65201840, RV3, RV5, RV8, RV12 pump parts
Get started with your repair:
We can have a repair estimate ready for your equipment within the hour of submission.
Start your equipment repair process by creating a Service RMA.
High quality service guaranteed
A&J Vacuum Services provides repairs on all types of High Vacuum equipment. We perform Turbomolecular Pump repair, Turbo Pump Repair, Dry Pump repair, Vacuum Pump repair and Mass Spectrometer repair. Our highly trained technicians will deliver the highest quality service and satisfaction.
We operate at our own full service repair facility which allows us to quickly and economically perform all repairs in a timely manner. Our advandced machinery enables us to handle all facets of the service and repair process. AJVS utilizes industry standard vibration analysis equipment and advanced testing equipment to troubleshoot and minimize all equipment failures. Our in-house machine shop is capable of machining various components, prototypes and housing conversions as needed.
AJVS repair process:
Repair Steps
- Full incoming inspection and run up time check, vibration check, drive inspection.
- Full disassembly of the pump, decontamination and cleaning.
- Pump is balanced utilizing state-of-the-art equipment from the world leader in equipment balancing and analysis to reduce noise and vibrations and extend bearings life.
- Assembly and replacement of all necessary parts such as shafts, bushings, bearings, sleeves, O-rings, gaskets, seals, wicks, etc. Only parts that meet or surpass OEM specifications are used to ensure dependable highest quality service and log pump life.
- Final test and leak check. The pump in fully assembled condition is checked for vacuum seal. Leak test to 1 x 10 -Mbar l/s. Vibrations are analyzed and test data is digitally recorded.
