- Pumping Speed (50/60 Hz): 22.7 / 27.7 cfm
- Ultimate Pressure: < 1.1 Torr
- Mains Connection: 200-240V, 1-ph, 50/60 Hz
- Inlet Connection: KF-40
Shopping Cart ( )
Leybold SOGEVAC SV 65 BIFC Vacuum Pump, LVO702, 1-ph, 200-240 V, 50/60 Hz, 960465V013002
Condition:
New
Item#:PN56594
Mfr Part#:960465V013002
Manufacturer:Leybold
Price upon request
CONTACT US
Features:
Leybold SOGEVAC SV 65 BIFC Vacuum Pump, LVO702, 1-ph, 200-240 V, 50/60 Hz, 960465V013002
Leybold SOGEVAC SV 65 BIFC Features:
- Upgraded electronic drive
- Compact design and small footprint
- Very low and constant noise level in any working condition
- Integrated functions, no external pipe
- Simplified maintenance
SOGEVAC SV 65 BIFC / 960465V013002 Overview:
The Leybold SOGEVAC SV65 BIFC range of Oil Sealed Vacuum Pumps is setting new standards in the vacuum industry. Offers new upgraded electronic drive.
The new SOGEVAC pumps allow space saving in your developments with minimum customer design constraints. It can also replace almost any pump in the field without requiring special adaptations.
Improved lubrication circuits and mechanical tolerances provide a constant low noise level at all working pressures. This provides a new standard in work area comfort to those operating your system. All lubrication circuits as well as the gas ballast system have been integrated into the pumps’ major components allowing limited sealings and a reduced number of parts. As a result, improved product reliability and durability is gained with prolonged maintenance intervals.
The pumps carry on with the proven and user-friendly maintenance concept of the former generation. All maintenance points are located on the front of the pump. Enhancements include an unambiguous angle mounted oil-sight glass offering visibility from two sides and a unique system that allows an easier exhaust demister replacement. Oil capacity 2 liters.
SOGEVAC SV65BIFC Applications:
- Vacuum packaging
- Vacuum processing
- Central vacuum systems
- Degassing
- Drying / Filling
- Freeze Drying
- Impregnation
- Leak testing
- Laser
- Handling / Lifting
A&J Vacuum Repair / Rebuild and Service Oerikon Leybold SOGEVAC SV 65 BI FC / 960465V0130002 Vacuum Pumps, Oerlikon Leybold Turbo Pumps along with all other Leybold Vacuum Rotary Vane Pumps, Leybold Dry Scroll Pump repair, Leybold Leak Detector Repair. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
Leybold SOGEVAC SV 65 BIFC Vacuum Pump, LVO702, 1-ph, 200-240 V, 50/60 Hz, 960465V013002
Leybold SOGEVAC SV 65 BIFC Technical Data:
- Nominal pumping speed (50/60 Hz): 71 m3/h
- Pumping speed (Norme PNEUROP - 50/60 Hz): ≥ 50 m3/h à 2 mbar
- Ultimate partial pressure without gas ballast: ≤ 0,2 mbar
- Ultimate partial pressure with small gas ballast: ≤ 1,0 mbar
- Water vapour tolerance -
- With small gas ballast approx.: 10 mbar
- Water vapour tolerable load -
- With small gas ballast approx.: 0,41 kg.h^-1
- Noise level (Norme DIN 46 635): ≤ 60 dB(A)
- Motor power - Rated rotational speed: 1,5-1800 kW - min^-1
- Mains voltage (+/- 10%) AC ~: 200 ... 240 V
- Protection Insulation: IP 20 - F
- Leak rate: <1 x 10^-3 mbar.l.s^-1
- Ambient temperature: 18 ... 40 °C
- Gas ballast: 0.5 m3/h
- Inlet flange: 40 KF
- Exhaust: 1/2 Barbed hose fitting
- OIL: Ester LVO 200 / L20002 - 2 Liters
- Shaft seal: Dynamic
- Sub-D type: 9 Male
- Control: Analog pins 9 and 8
- Mains Socket Type: HIRCHMANN CA3GS
- On/Off Switch: No
- Current Overload: 2 Fuses / 12.5 A
A&J Vacuum Repair / Rebuild and Service Oerikon Leybold SOGEVAC SV 65 BI FC / 960465V0130002 Vacuum Pumps, Oerlikon Leybold Turbo Pumps along with all other Leybold Vacuum Rotary Vane Pumps, Leybold Dry Scroll Pump repair, Leybold Leak Detector Repair. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.
