- Includes a Cutting-Edge Rotor and High-Performance Drag Stage Design
- High Pumping Speed for Four Distinct Gases: Nitrogen, Argon, Helium, and Hydrogen
- Utilizes Convection Standard Cooling Method; Advanced Temperature Stability
- Incorporates DN 100 ISO-K Inlet Flange; DN 16 ISO-KF Outlet Flange
Shopping Cart ( )
Leybold Turbovac 250 i High-Vacuum Turbo Pump, RS 485, DN 100 ISO-K, 820051V1000
Condition:
Remanufactured
In Stock
Item#:PN58090
Mfr Part#:820051V1000
Manufacturer:Leybold
Features:
Leybold Turbovac 250 i High-Vacuum Turbo Pump, RS 485, DN 100 ISO-K, 820051V1000
Leybold Turbovac 250 i Features:
- Ultimate pressure: < 8.0 x 10-8 mbar
- Pumping speed (Ar): 210 l/s
- Pumping speed (He): 250 l/s
- Pumping speed (H₂): 210 l/s
- Pumping speed (N₂): 225 l/s
- High pressure foreline tolerance
- Excellent resistance to vibration due to proven mechanical bearings
- Efficient convection cooling due to a large number of cooling fans
Turbovac 250 i / 820051V1000 Overview:
The Leybold Turbovac i line brings the latest hybrid bearing design, ultimately offering the cleanest high vacuum conditions. The pumps are available with a compact interface which offers the control of one to two accessories, basic RS 485, USB and DIGITAL I/O control. In general, the pumps come stand-alone.
With the Leybold Turbovac 250 i, high functionality meets outstanding performance. Our model 250 i turbomolecular pump range with an integrated vacuum system controller provides many features that have, until now, been available only in costly external pump control units. The Turbovac 250 i turbo pump has a pumping speed of 225 l/s of N2 (Nitrogen).
Designed to offer the best performance-to-size ratio within the ISO 63, 100 and 160 flange size range, the Leybold Turbovac 250 i features a cutting-edge rotor and drag stage design, contributing to high performance and unparalleled pumping speeds, especially for light gas varieites.
Turbovac 250 i offers USB+ and a 15-pin digital I/O interface. A wide selection of interface options, housing and flange configurations, as well as accessories completes this product line. The unique oil-free hybrid bearing system with lifetime-lubricated ball bearings will likewise boost your productivity and reduce the cost of ownership.
Turbovac 250i comes without any additional cooling device.
Turbovac250i Applications:
- Analytical technologies / Research & Development
- Mass spectrometers
- Electron microscopes
- Surface analysis
- X-ray-analysis
- Particle accelerators and synchrotons
- Laboratory coating systems
- MBE (Molecular Beam Epitaxy)
- UHV systems
- Life Sciences
- Proton therapy
- Gamma sterilisation
- Production of high quality implants
- Industrial and Coating applications
- PVD- Physical Vapour deposition
- Optical coatings
- CD/DVD/Bly-Ray Disc production
- Thin film technologies, photovoltaics
- Wear protection
- Heat treatment
- Electron beam welders
- Load locks, transfer chambers, handling systems
- Insulation vacuum and leak detection
A&J Vacuum Services offers full repair and service of Leybold Turbovac 250i High-Vacuum Pumps, along with all other brands of Leybold Turbo Pumps offered on our website. Please contact us for more information about our service and repair program or click http://www.ajvs.com/service.php to access our services page. We also offer emergency service upon request. For more information, please email A&J Vacuum Services at info@ajvs.com or call (973) 249-0854. Thank you for choosing AJVS as your supplier.
This item is non-returnable/non-refundable
Leybold Turbovac 250 i High-Vacuum Turbo Pump, RS 485, DN 100 ISO-K, 820051V1000
Leybold Turbovac 250 i Technical Data:
| Connection Cooling |
6x1 mm flexible hose quick connection |
| Connection Outlet Flange | DN 16 ISO-KF (NW16) |
| Connection Inlet Flange | DN 100 ISO-K |
| Cooling Method | Air Cooling (convection) Air Cooling (forced - fan) Water Cooling |
| Dimension Height | 0.196 m |
| Dimension Length | 0.130 m |
| Dimension Width | 0.130 m |
| IP Rating | IP40 |
| Noise / Sound Level | 41.00 db(A) 41.00 db(A) 41.00 db(A) |
| Supply Frequency | DC Voltage |
| Supply Voltage | DC 24V DC 48V |
| Weight | 4.00 kg | 9 lb |
| Connection Inlet / Outlet Flange | DN 100 ISO-K | DN 16 ISO-KF (NW16) |
| Product Certification | CE UL (61010-1 3rd Edition) CSA (C22.2 No.61010-1-12) |
| Connection Purge Gas, Gas Ballast, Vent | 1/8" BSPP (or G 1/8") Female 1/8" BSPP (or G 1/8") Female |
| Temperature Ambient Operation Max | 40.00 °C | 104.00 °F | 313.15 K |
| Temperature Ambient Storage Max | 70.00 °C | 158.00 °F | 343.15 K |
| Temperature Ambient Operation Min | 5.00 °C | 41.00 °F | 278.15 K |
| Temperature Ambient Storage Min | -15.00 °C | 5.00 °F | 258.15 K |
| Magnetic Field Resistance Max (covering worst direction - come and consult us for more details) | 5.500 × 10⁻³ T |
| Dry or Wet Pump | Dry |
| Product Pressure Range | High Vacuum: 1·10⁻³ - 1·10⁻⁷ mbar |
| High / Medium / Rough Vacuum Classification | High Vacuum Pump |
| Vacuum Pump Technology | Turbomolecular Pump - hybrid bearing oil free |
| Compression Ratio Air Nitrogen | 1.000 × 10¹¹ |
| Compression Ratio Helium | 1.000 × 10⁸ |
| Compression Ratio Hydrogen | 2.000 × 10⁷ |
| Power Consumption Max | 240 W |
| Power Total Rated | 240 W |
| Pressure Ultimate | 8.000 × 10⁻⁸ mbar |
| Pumping Speed Air Nitrogen (@50Hz or max @default setting) | 225.00 l/s |
| Pumping Speed Argon | 210.00 l/s |
| Pumping Speed Helium | 250.00 l/s |
| Pumping Speed Hydrogen | 210.00 l/s |
| Ramp Up Time | 120 s |
| Nominal rotational speed | 1200 Hz |
| Pressure Backing Max | 14 mbar |
| Compression Ratio Argon | 1.000 × 10¹¹ |
| Communication Interface Protocol | USS Universal Serial Interface Protocol |
| Communication Interfaces Customer | RS485 (serial) REMOTE X1 (Parallel I/O) USB |
| Connection electrical comms interface connector | DSUB 9-PIN - Male DSUB HD 15-PIN - Female (high density) USB type B - Female |
| Installation | Any orientation |
| variantTmpPerformanceModel | TURBOVAC i - frontend 1 (basic) |
| Flow Cooling Water Min | 8.333 × 10⁻³ l/s |
| Temperature Cooling Water Max | 35.00 °C | 95.00 °F | 308.15 K |
| Temperature Cooling Water Min | 15.00 °C | 59.00 °F | 288.15 K |
| Flow Cooling Water Max | 0.017 l/s |
| Pressure Permissible Supply Cooling Water - Min and Max | 4000.00 mbar 4000.00 mbar |
