Centering Ring KF 10 With Viton® O-Ring, KF 10 (NW 10), Stainless Steel, The centering ring contains a rubber elastomeric fluorocarbon o-ring. Those are also recognized as NW10, NW16, NW25, NW40, or KF-10 KF-16, KF-25, KF-40 and KF-50, KF10CRVS, 304 SS
Stainless Steel ring with Viton® O-ring, KF10CRVS
- A: 0.39 in / 10 mm
- B: 0.47 in / 12 mm
- C: 0.31 in / 8 mm
- D: 0.15 in / 3.9 mm
Overview:
The Centering Rings are available in the following sizes: NW 10, NW 16, NW 25, NW 40, NW 50.
The Centering Rings are available in Aluminum / Viton®, Aluminum / NBR, Stainless Steel / Viton® or Stainless Steel / NBR.
The centering ring contains a rubber elastomer fluorocarbon o-ring. Those are also recognized as NW10, NW16, NW25, NW40, or KF-10 KF-16, KF-25, KF-40 and KF-50
Standard sizes for quick flange fittings are KF-10, KF-16, KF-25 and KF-50 with Flange sizes NW-10, NW16, NW-25, NW-40
KF (also referred to as NW) assemblies consist of two Flanges, a Center Viton® O-Ring and an aluminum Clamp. Clamps are assembled with wing nuts to insure ease of use over time without tools. A uniform application of pressure on the clamp insures a vacuum seal. The mating flange surfaces compress the O-Ring, which is held in place by a metal centering ring, to generate the vacuum seal.
Corrosive resistant stainless steel (316) with Viton® O-ring provides great resistance to heat and agressive chemicals.
Viton® is a registered treadmark of DuPont Performance Elastomers
Centering Ring KF 16 With Viton® O-Ring, KF 16 (NW 16), Stainless Steel, The centering ring contains a rubber elastomeric fluorocarbon o-ring. Those are also recognized as NW10, NW16, NW25, NW40, or KF-10 KF-16, KF-25, KF-40 and KF-50, KF16CRVS, 304 SS
Stainless Steel ring with Viton® O-ring, KF16CRVS
- A: 0.63 in / 16 mm
- B: 0.67 in / 17 mm
- C: 0.31 in / 8 mm
- D: 0.15 in / 3.9 mm
Overview:
The Centering Rings are available in the following sizes: NW 10, NW 16, NW 25, NW 40, NW 50.
The Centering Rings are available in Aluminum / Viton®, Aluminum / NBR, Stainless Steel / Viton® or Stainless Steel / NBR.
The centering ring contains a rubber elastomer fluorocarbon o-ring. Those are also recognized as NW10, NW16, NW25, NW40, or KF-10 KF-16, KF-25, KF-40 and KF-50
Standard sizes for quick flange fittings are KF-10, KF-16, KF-25 and KF-50 with Flange sizes NW-10, NW16, NW-25, NW-40
KF (also referred to as NW) assemblies consist of two Flanges, a Center Viton® O-Ring and an aluminum Clamp. Clamps are assembled with wing nuts to insure ease of use over time without tools. A uniform application of pressure on the clamp insures a vacuum seal. The mating flange surfaces compress the O-Ring, which is held in place by a metal centering ring, to generate the vacuum seal.
Corrosive resistant stainless steel (316) with Viton® O-ring provides great resistance to heat and agressive chemicals.
Viton® is a registered treadmark of DuPont Performance Elastomers
Centering Ring KF 25 With Viton® O-Ring, KF 25 (NW 25), Stainless Steel, The centering ring contains a rubber elastomeric fluorocarbon o-ring. Those are also recognized as NW10, NW16, NW25, NW40, or KF-10 KF-16, KF-25, KF-40 and KF-50, KF25CRVS, 304 SS
Stainless Steel ring with Viton® O-ring, KF25CRVS
- A: 0.98 in / 25 mm
- B: 1.02 in / 26 mm
- C: 0.31 in / 8 mm
- D: 0.15 in / 3.9 mm
Overview:
The Centering Rings are available in the following sizes: NW 10, NW 16, NW 25, NW 40, NW 50.
The Centering Rings are available in Aluminum / Viton®, Aluminum / NBR, Stainless Steel / Viton® or Stainless Steel / NBR.
The centering ring contains a rubber elastomer fluorocarbon o-ring. Those are also recognized as NW10, NW16, NW25, NW40, or KF-10 KF-16, KF-25, KF-40 and KF-50
Standard sizes for quick flange fittings are KF-10, KF-16, KF-25 and KF-50 with Flange sizes NW-10, NW16, NW-25, NW-40
KF (also referred to as NW) assemblies consist of two Flanges, a Center Viton® O-Ring and an aluminum Clamp. Clamps are assembled with wing nuts to insure ease of use over time without tools. A uniform application of pressure on the clamp insures a vacuum seal. The mating flange surfaces compress the O-Ring, which is held in place by a metal centering ring, to generate the vacuum seal.
Corrosive resistant stainless steel (316) with Viton® O-ring provides great resistance to heat and agressive chemicals.
Viton® is a registered treadmark of DuPont Performance Elastomers
Centering Ring KF 40 With Viton® O-Ring, KF 40 (NW 40), Stainless Steel, The centering ring contains a rubber elastomeric fluorocarbon o-ring. Those are also recognized as NW10, NW16, NW25, NW40, or KF-10 KF-16, KF-25, KF-40 and KF-50, KF40CRVS, 304 SS
Stainless Steel ring with Viton® O-ring, KF40CRVS
- A: 1.57 in / 40 mm
- B: 1.61 in / 41 mm
- C: 0.31 in / 8 mm
- D: 0.15 in / 3.9 mm
Overview:
The Centering Rings are available in the following sizes: NW 10, NW 16, NW 25, NW 40, NW 50.
The Centering Rings are available in Aluminum / Viton®, Aluminum / NBR, Stainless Steel / Viton® or Stainless Steel / NBR.
The centering ring contains a rubber elastomer fluorocarbon o-ring. Those are also recognized as NW10, NW16, NW25, NW40, or KF-10 KF-16, KF-25, KF-40 and KF-50
Standard sizes for quick flange fittings are KF-10, KF-16, KF-25 and KF-50 with Flange sizes NW-10, NW16, NW-25, NW-40
KF (also referred to as NW) assemblies consist of two Flanges, a Center Viton® O-Ring and an aluminum Clamp. Clamps are assembled with wing nuts to insure ease of use over time without tools. A uniform application of pressure on the clamp insures a vacuum seal. The mating flange surfaces compress the O-Ring, which is held in place by a metal centering ring, to generate the vacuum seal.
Corrosive resistant stainless steel (316) with Viton® O-ring provides great resistance to heat and agressive chemicals.
Viton® is a registered treadmark of DuPont Performance Elastomers
Centering Ring KF 50 With Viton® O-Ring, KF 50 (NW 50), Stainless Steel, The centering ring contains a rubber elastomeric fluorocarbon o-ring. Those are also recognized as NW10, NW16, NW25, NW40, or KF-10 KF-16, KF-25, KF-40 and KF-50, KF50CRVS, 304 SS
Stainless Steel ring with Viton® O-ring, KF50CRVS
- A: 1.97 in / 50 mm
- B: 2.05 in / 52 mm
- C: 0.31 in / 8 mm
- D: 0.15 in / 3.9 mm
Overview:
The Centering Rings are available in the following sizes: NW 10, NW 16, NW 25, NW 40, NW 50.
The Centering Rings are available in Aluminum / Viton®, Aluminum / NBR, Stainless Steel / Viton® or Stainless Steel / NBR.
The centering ring contains a rubber elastomer fluorocarbon o-ring. Those are also recognized as NW10, NW16, NW25, NW40, or KF-10 KF-16, KF-25, KF-40 and KF-50
Standard sizes for quick flange fittings are KF-10, KF-16, KF-25 and KF-50 with Flange sizes NW-10, NW16, NW-25, NW-40
KF (also referred to as NW) assemblies consist of two Flanges, a Center Viton® O-Ring and an aluminum Clamp. Clamps are assembled with wing nuts to insure ease of use over time without tools. A uniform application of pressure on the clamp insures a vacuum seal. The mating flange surfaces compress the O-Ring, which is held in place by a metal centering ring, to generate the vacuum seal.
Corrosive resistant stainless steel (316) with Viton® O-ring provides great resistance to heat and agressive chemicals.
Viton® is a registered treadmark of DuPont Performance Elastomers
Centering Ring Adapter KF-10 to KF-16, NW10/16, With Viton® O-Ring Stainless Steel, KF10/16, PN40708
NW10 to NW16 O-ring Adapter Overview:
These adapting rings are used to addopt NW10 to NW16 flanges Edwards C10512345
The Centering Rings are available in Aluminum / Viton®, Aluminum / NBR, Stainless Steel / Viton® or Stainless Steel / NBR.
The centering ring contains a rubber elastomer fluorocarbon o-ring. Those are also recognized as NW10, NW16, NW25, NW40, or KF-10 KF-16, KF-25, KF-40 and KF-50
KF (also referred to as NW) assemblies consist of two Flanges, a Center Viton® O-Ring and an aluminum Clamp. Clamps are assembled with wing nuts to insure ease of use over time without tools.
Corrosive resistant stainless steel (316) with Viton® O-ring provides great resistance to heat and agressive chemicals.
Viton® is a registered treadmark of DuPont Performance Elastomers
