Vacuubrand MD 1 Diaphragm Vacuum Pump, Ultimate Pressure 1.5 mbar, Pumping Speed 0.82 cfm, 100-120V / 200-230V 50/60 Hz, 696083 / 20696083

Vacuubrand MD 1 Features:

• Contamination free vacuum pumping
• High flow rate even near ultimate vacuum
• Excellent ultimate vacuum
• Whisper quiet and low vibration
• Long diaphragm life, maintenance free drive system design

MD 1 / 20696083 Overview:

The Vacuubrand MD1 diaphragm pump is an excellent choice for oil-free evacuation and pumping of non-corrosive gases down to 1.5 mbar ultimate vacuum.

The three-stage design with precisely guided flat diaphragms provides outstanding pumping speed even close to the ultimate vacuum, especially when compared with similarly rated two-stage diaphragm pumps.

The Vacuubrand MD1 is an ultra-low vibration pump with very long diaphragm lilfetimes and stable ultimate vacuum documented with years of testing.

With a flow path consisting of aluminum and selected plastics (diaphragms and valves made of PTFE/FKM and FKM, respectively) the Vacuubrand MD1 pumps are suitable for a wide range of applications with non-corrosive gases.

MD1 Scope of Delivery:

• Pump completely mounted
• Manual

MD1 Applications:

• Drying
• Rotary evaporation
• Vacuum concentration
• Filtration
• Local area vacuum networks
• Reactors & synthesis applications
• Fore vacuum generation for turbomolecular pumps

A&J Vacuum Services, Inc is a Authorized Vacuubrand Service Facility. We repair / rebuild and service all Vacuubrand Diaphragm pumps, Rotary Vane Vacuum Pumps, and all other Vacuubrand equipment. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.

Vacuubrand MD 4 NT Diaphragm Vacuum Pump, 100 - 120V / 50 - 60Hz, US Power Cord, 2.5 CFM, 1 mbar, 736000 / 20736000

Vacuubrand MD 4 NT Features:

• ​Super quiet
• Ultra low vibration
• High chemical resistance
• Space saver
• Simple to use
• Maintenance free drive system

MD 4 NT / 20736000 Overview:

These three-stage diaphragm pumps are an excellent solution for continuous, oil-free pumping of non-corrosive gases. They reach an excellent ultimate vacuum of 1 mbar.

All parts in contact with pumped gases and vapors are made of aluminum, stainless steel and carefully selected plastics suitable for a wide range of applications with non-corrosive gases.

The new NT-series provides whisper quiet and ultra-low vibration operation, high leak tightness and improved performance.

The highly flexible fabric-reinforced double diaphragm made of FKM is ideal for extended operating life.

MD4NT Scope of Delivery:

• Pump completely mounted
• Manual

MD4NT Applications:

• Drying
• Rotary evaporation
• Vacuum concentration
• Filtration
• Local area vacuum networks
• Reactors & synthesis applications
• Fore vacuum generation for turbomolecular pumps

A&J Vacuum Services, Inc is a Authorized Vacuubrand Service Facility. We repair / rebuild and service all Vacuubrand Diaphragm pumps, Rotary Vane Vacuum Pumps, and all other Vacuubrand equipment. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.

Please Note: This pump has been replaced with new model with a new motor specification. Please follow this link to view replacement model. Click Here

Vacuubrand MD 1 Diaphragm Vacuum Pump, Ultimate Pressure 1.5 mbar, Pumping Speed 0.7 cfm, 100-120V/200-230V 50/60 Hz, Vacuubrand MD1, 696087 / 20696087

The Vacuubrand MD1 diaphragm pump is an excellent choice for oil-free evacuation and pumping of non-corrosive gases down to 1.5 mbar ultimate vacuum.

The three-stage design with precisely guided flat diaphragms provides outstanding pumping speed even close to the ultimate vacuum, especially when compared with similarly rated two-stage diaphragm pumps.

The Vacuubrand MD1 is an ultra-low vibration pump with very long diaphragm lilfetimes and stable ultimate vacuum documented with years of testing.

With a flow path consisting of aluminum and selected plastics (diaphragms and valves made of PTFE/FKM and FKM, respectively) the Vacuubrand MD1 pumps are suitable for a wide range of applications with non-corrosive gases.

Features:

• Contamination free vacuum pumping

• High flow rate even near ultimate vacuum

• Excellent ultimate vacuum

• Whisper quiet and low vibration

• Longong diaphragm life, maintenance free drive system design

A&J Vacuum Services, Inc is a Authorized Vacuubrand Service Facility. We repair / rebuild and service all Vacuubrand Diaphragm pumps, Rotary Vane Vacuum Pumps, and all other Vacuubrand equipment. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.

Vacuubrand MD 4 NT Diaphragm Vacuum Pump, 100 - 120V / 50 - 60Hz, US Power Cord, 2.5 CFM, 1 mbar, 736003 / 20736003

Vacuubrand MD 4 NT Features:

• ​Super quiet
• Ultra low vibration
• High chemical resistance
• Space saver
• Simple to use
• Maintenance free drive system

MD 4 NT / 20736003 Overview:

These three-stage diaphragm pumps are an excellent solution for continuous, oil-free pumping of non-corrosive gases. They reach an excellent ultimate vacuum of 1 mbar.

All parts in contact with pumped gases and vapors are made of aluminum, stainless steel and carefully selected plastics suitable for a wide range of applications with non-corrosive gases.

The new NT-series provides whisper quiet and ultra-low vibration operation, high leak tightness and improved performance.

The highly flexible fabric-reinforced double diaphragm made of FKM is ideal for extended operating life.

MD4NT Scope of Delivery:

• Pump completely mounted
• Manual

MD4NT Applications:

• Drying
• Rotary evaporation
• Vacuum concentration
• Filtration
• Local area vacuum networks
• Reactors & synthesis applications
• Fore vacuum generation for turbomolecular pumps

A&J Vacuum Services, Inc is a Authorized Vacuubrand Service Facility. We repair / rebuild and service all Vacuubrand Diaphragm pumps, Rotary Vane Vacuum Pumps, and all other Vacuubrand equipment. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.

Vacuubrand MD 4 NT Diaphragm Vacuum Pump, 100 - 120V / 200 - 230V, 50 - 60Hz, US Power Cord, 2.5 CFM, 1 mbar, 736005 / 20736005

Vacuubrand MD 4 NT Features:

• ​Super quiet
• Ultra low vibration
• High chemical resistance
• Space saver
• Simple to use
• Maintenance free drive system

MD 4 NT / 20736005 Overview:

These three-stage diaphragm pumps are an excellent solution for continuous, oil-free pumping of non-corrosive gases. They reach an excellent ultimate vacuum of 1 mbar.

All parts in contact with pumped gases and vapors are made of aluminum, stainless steel and carefully selected plastics suitable for a wide range of applications with non-corrosive gases.

The new NT-series provides whisper quiet and ultra-low vibration operation, high leak tightness and improved performance.

The highly flexible fabric-reinforced double diaphragm made of FKM is ideal for extended operating life.

MD4NT Scope of Delivery:

• Pump completely mounted
• Manual

MD4NT Applications:

• Drying
• Rotary evaporation
• Vacuum concentration
• Filtration
• Local area vacuum networks
• Reactors & synthesis applications
• Fore vacuum generation for turbomolecular pumps

A&J Vacuum Services, Inc is a Authorized Vacuubrand Service Facility. We repair / rebuild and service all Vacuubrand Diaphragm pumps, Rotary Vane Vacuum Pumps, and all other Vacuubrand equipment. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.

Vacuubrand MD 12 NT Diaphragm Vacuum Pump, 100 - 120V / 50 - 60Hz, US Power Cord, 7.5 CFM, 2 mbar, 743003 / 20743003

Vacuubrand MD 12 NT Features:

• ​Super quiet
• Ultra low vibration
• High chemical resistance
• Space saver
• Simple to use
• Maintenance free drive system

MD 12 NT / 20743003 Overview:

The MD 12 NT diaphragm pump is an especially powerful pump for oil-free evacuation and pumping of non aggressive gases.

The three-stage design of this eight-cylinder pump provides the advantageous combination of very high pumping speed and excellent ultimate vacuum. The flow path consists of aluminum, stainless steel and carefully selected plastics to permit a wide range of applications. The fabric-reinforced double diaphragms are made of highly flexible FKM for extended operating life and high vacuum performance.

Eight-cylinder NT pumps feature quiet operation, with smooth and easy-to-clean surfaces.

Like all VACUUBRAND diaphragm pumps they operate absolutely oil-free and do not have any sliding components in the gas path. In normal operation they are completely free of abrasion. This eliminates most of the particulate impurities frequently generated inside of scroll or piston pumps.

MD12NT Scope of Delivery:

• Pump completely mounted
• Manual

MD12NT Applications:

• Drying
• Rotary evaporation
• Vacuum concentration
• Filtration
• Local area vacuum networks
• Reactors & synthesis applications
• Fore vacuum generation for turbomolecular pumps

A&J Vacuum Services, Inc is a Authorized Vacuubrand Service Facility. We repair / rebuild and service all Vacuubrand Diaphragm pumps, Rotary Vane Vacuum Pumps, and all other Vacuubrand equipment. Please contact us for information on service program or click here http://www.ajvs.com/service.php to go to our Service page. We also offer Emergency service upon request. For more information Please contact A&J Vacuum Services at 973-249-0854.

Vacuubrand MD 12 NT Diaphragm Vacuum Pump, 100 - 120V / 50 - 60Hz, US Power Cord, 7.1 CFM, 2 mbar, 743003 / 20743003
